ViO55-6B Yanmar excavator specs & dimensions (2019 - 2025)

Yanmar ViO55-6B is a mini excavator manufactured since 2019, with a weight of 5.25 tons. It features a track width of 400 mm, a tr…

Yanmar ViO55-6B is a mini excavator manufactured since 2019, with a weight of 5.25 tons. It features a track width of 400 mm, a transport length of 5.58 meters, a transport width of 1.99 meters, and a transport height of 2.54 meters. The machine has a tear-out force of 33.2 kN, a dredging depth of 3.9 meters, and a maximum horizontal reach of 4.05 meters. The bucket width is 0.7 meters with a capacity of 0.16 cubic meters. It is equipped with a blade as special equipment.

Mini Excavators Yanmar ViO55-6B

Technical specs - ViO55-6B Yanmar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
5.25 t
Transport length
5.58 m
Transport width
1.99 m
Transport height
2.54 m
Bucket capacity
0.16 m³
Bucket width
0.7 m
Track width
400 mm
Max. Reach horizontal
4.05 m
Dredging depth
3.9 m
Tear-out force
33.2 kN
Model series
VIO
Engine manuf.
Yanmar
Engine type
4TNV84T-ZMBV
Engine power
33.4 kW

More technical details, like: bucket capacity min., bucket capacity max., standard tyres, driver protection, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
No
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Yanmar ViO55-6B FAQ

When was the Yanmar ViO55-6B manufactured?

The Yanmar ViO55-6B was first produced in 2019.

How much does the Yanmar ViO55-6B weigh?

The Yanmar ViO55-6B weighs 5.25 tons.

What are the transport dimensions of the Yanmar ViO55-6B mini excavator?

The Yanmar ViO55-6B has a transport length of 5.58 meters, a transport width of 1.99 meters, and a transport height of 2.54 meters.

What is the track width of the Yanmar ViO55-6B mini excavator?

The Yanmar ViO55-6B mini excavator has a track width of 400 mm.

What are the excavation performance specifications of the Yanmar ViO55-6B mini excavator?

The Yanmar ViO55-6B has a dredging depth of 3.9 meters and a maximum horizontal reach of 4.05 meters.

What is the tear-out force of the Yanmar ViO55-6B mini excavator?

The Yanmar ViO55-6B mini excavator has a tear-out force of 33.2 kN. No power rating data is provided for this model.

What are the bucket specifications of the Yanmar ViO55-6B mini excavator?

The Yanmar ViO55-6B has a bucket capacity of 0.16 cubic meters and a bucket width of 0.7 meters.

How much is a Yanmar ViO55-6B Mini excavator (2019u20132025) worth?

The residual value of the Yanmar ViO55-6B depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
