Technical specs - ViO27LW-6 Yanmar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.665 t

Transport length: 4.6 m

Transport width: 1.5 m

Transport height: 2.53 m

Track width: 260 mm

Driver protection: Kb

Max. Reach horizontal: 4.69 m

Dredging depth: 2.74 m

Tear-out force: 23.1 kN

Model series: ViO

Engine manuf.: Yanmar

Engine type: 3TNV76-NBVA1

Engine power: 15.2 kW

Displacement: 1.115 l

Revolutions at max torque: 2500 rpm

Max. torque: 69,1/1800 Nm

No. of cylinders: 3

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: Yes
Rubber track: Yes
Blade: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Yanmar ViO27LW-6 FAQ

When was the Yanmar ViO 27LW-6 manufactured?

The Yanmar ViO 27LW-6 was first produced in 2024.

How much does the Yanmar ViO 27LW-6 weigh?

The Yanmar ViO 27LW-6 weighs 2.665 tons.

What are the transport dimensions of the Yanmar ViO 27LW-6 mini excavator?

The Yanmar ViO 27LW-6 has a transport length of 4.6 meters, a transport width of 1.5 meters, and a transport height of 2.53 meters.

What is the track width of the Yanmar ViO 27LW-6 mini excavator?

The Yanmar ViO 27LW-6 has a track width of 260 mm.

What are the excavation performance specifications of the Yanmar ViO 27LW-6?

The Yanmar ViO 27LW-6 has a dredging depth of 2.74 meters and a maximum horizontal reach of 4.69 meters.

What is the tear-out force of the Yanmar ViO 27LW-6 mini excavator?

The Yanmar ViO 27LW-6 has a tear-out force of 23.1 kN.

What operator safety features does the Yanmar ViO 27LW-6 have?

The Yanmar ViO 27LW-6 has a cabin for driver protection.

How much is a Yanmar ViO 27LW-6 Mini excavator (2024u20132025) worth?

The residual value of the Yanmar ViO 27LW-6 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
