ViO17 Yanmar excavator specs & dimensions (2024 - 2026)

Weight: 1.83t – Transport length: 3.81m – Transport width: 1.28m – Transport height: 2.3m – Track width: 230mm – Driver protection…

Weight: 1.83t – Transport length: 3.81m – Transport width: 1.28m – Transport height: 2.3m – Track width: 230mm – Driver protection: FD

Check out detailed specifications, information and technical data for Yanmar ViO17 excavator manufactured between 2024 - 2026. Get more in-depth insight with Yanmar ViO17 digger specifications. See information, like: Weight: 1.83t – Transport length: 3.81m – Transport width: 1.28m – Transport height: 2.3m – Track width: 230mm – Driver protection: FD and more.

Mini Excavators Yanmar ViO17
Mini Excavators Yanmar ViO17
Mini Excavators Yanmar ViO17
Mini Excavators Yanmar ViO17
Mini Excavators Yanmar ViO17
Mini Excavators Yanmar ViO17
Mini Excavators Yanmar ViO17
Mini Excavators Yanmar ViO17
Mini Excavators Yanmar ViO17
Mini Excavators Yanmar ViO17

Technical specs - ViO17 Yanmar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.83 t
Transport length
3.81 m
Transport width
1.28 m
Transport height
2.3 m
Track width
230 mm
Driver protection
FD
Max. Reach horizontal
3.81 m
Dredging depth
2.41 m
Tear-out force
16.1 kN
Model series
ViO
Engine manuf.
Yanmar
Engine type
3TNV70-XBV
Engine power
10.1 kW
Displacement
0.854 l
Revolutions at max torque
2200 rpm
Max. torque
52/1600 Nm
No. of cylinders
3
Emission level
V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
Yes
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Yanmar ViO17 FAQ

When was the Yanmar ViO 17 manufactured?

The Yanmar ViO 17 was first produced in 2024.

How much does the Yanmar ViO 17 weigh?

The Yanmar ViO 17 weighs 1.83 tons.

What are the transport dimensions of the Yanmar ViO 17 mini excavator?

The Yanmar ViO 17 has a transport length of 3.81 meters, a transport width of 1.28 meters, and a transport height of 2.3 meters.

What is the track width of the Yanmar ViO 17 mini excavator's undercarriage?

The Yanmar ViO 17 mini excavator has a track width of 230 mm.

What are the excavation performance specifications of the Yanmar ViO 17 mini excavator?

The Yanmar ViO 17 mini excavator has a dredging depth of 2.41 meters and a maximum horizontal reach of 3.81 meters.

What is the tear-out force of the Yanmar ViO 17 mini excavator?

The Yanmar ViO 17 mini excavator has a tear-out force of 16.1 kN.

What operator protection feature does the Yanmar ViO 17 have?

The Yanmar ViO 17 has a canopy for driver protection.

How much is a Yanmar ViO 17 Mini excavator (2024u20132025) worth?

The residual value of the Yanmar ViO 17 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
