Technical specs - XE10E XCMG

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.2 t
Transport length
2.96 m
Transport width
1.02 m
Transport height
2.45 m
Bucket capacity
0.022 m³
Track width
180 mm
Driver protection
FD
Max. Reach horizontal
3.3 m
Dredging depth
1.705 m
Tear-out force
11.5 kN
Model series
XE
Engine manuf.
Kubota
Engine type
D782
Engine power
9.8 kW
Displacement
0.778 l
Revolutions at max torque
2300 rpm
Max. torque
44,5/1800 Nm
No. of cylinders
3
Cylinder bore x stroke
67x73,6 mm
Emission level
V

More technical details, like: bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
No
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No
