EZ17 Wacker Neuson excavator specs & dimensions (2013 - 2019)

Model rating
10,00 / 10

Wacker Neuson EZ17 is a mini excavator manufactured from 2013 to 2019. It has a weight of 1.65 tons and a track width of 230 mm. T…

Wacker Neuson EZ17 is a mini excavator manufactured from 2013 to 2019. It has a weight of 1.65 tons and a track width of 230 mm. The transport dimensions are 3.585 meters in length, 0.99 meters in width, and 2.36 meters in height. The bucket width is 0.6 meters. Special equipment includes a blade and track adjustment.

Mini Excavators Wacker Neuson EZ17
Mini Excavators Wacker Neuson EZ17
Mini Excavators Wacker Neuson EZ17
Mini Excavators Wacker Neuson EZ17
Mini Excavators Wacker Neuson EZ17
Mini Excavators Wacker Neuson EZ17
Mini Excavators Wacker Neuson EZ17
Mini Excavators Wacker Neuson EZ17
Mini Excavators Wacker Neuson EZ17
Mini Excavators Wacker Neuson EZ17

Visit Wacker Neuson live at

Technical specs - EZ17 Wacker Neuson

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.65 t
Transport length
3.585 m
Transport width
0.99 m
Transport height
2.36 m
Bucket width
0.6 m
Track width
230 mm
Max. Reach horizontal
3.85 m
Dredging depth
2.33 m
Tear-out force
8.39 kN
Model series
EZ
Engine manuf.
Yanmar
Engine type
3TNV76
Engine power
13.4 kW
Displacement
1.116 l
Revolutions at max torque
2200 rpm
No. of cylinders
3

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., standard tyres, driver protection, dimension lxwxh, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
Yes
Rubber track
No
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Wacker Neuson EZ17 FAQ

When was the Wacker Neuson EZ17 manufactured?

The Wacker Neuson EZ17 was manufactured from 2013 to 2019.

How much does the Wacker Neuson EZ17 weigh?

The Wacker Neuson EZ17 weighs 1.65 tons.

What are the transport dimensions of the Wacker Neuson EZ17 mini excavator?

The Wacker Neuson EZ17 has a transport length of 3.59 meters, a transport width of 0.99 meters, and a transport height of 2.36 meters.

What is the track width of the Wacker Neuson EZ17's undercarriage?

The Wacker Neuson EZ17 has a track width of 230 mm.

What are the dredging depth and maximum horizontal reach of the Wacker Neuson EZ17 mini excavator?

The Wacker Neuson EZ17 mini excavator has a dredging depth of 2.33 meters and a maximum horizontal reach of 3.85 meters.

What is the tear-out force of the Wacker Neuson EZ17 mini excavator?

The Wacker Neuson EZ17 mini excavator has a tear-out force of 8.39 kN.

What is the bucket width of the Wacker Neuson EZ17 mini excavator?

The bucket width of the Wacker Neuson EZ17 mini excavator is 0.6 meters.

How much is a Wacker Neuson EZ17 Mini excavator (2013u20132019) worth?

The residual value of the Wacker Neuson EZ17 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Wacker Neuson EZ17 overview

Dimensions and weight

Flow rate396 l/min"
Operating pressure for working and traction hydraulics240 bar
Operating pressure Slewing gear150 bar
Hydraulic oil tank21 l
Shipping weight min.1.595 kg
Operating weight min.1.725 kg
Biting force max.839 kN"
Breakaway force max.1.876 daN
Digging depth2.330 mm
Dumping height max.2.440 mm
Digging radius3.900 mm
L x W x H3585 x 990 x 2360 mm"

Tables

Engine / Motor manufacturerYanmar
Engine / Motor type3TNV76
Engine / MotorWater-cooled 3-cylinder diesel engine
Displacement1.116 cm³
RPM / speed2.200 rpm
Engine performance output to ISO134 kW"
Battery30 Ah
Tank capacity22 l
Travel speed max.48 km/h"
Gradeability58 %
Chain width230 mm
Ground clearance160 mm
Sound level (LwA) acc. to 2000/14/EC93 dB(A)
Cabin - specified sound pressure level LpA acc. to ISO 639479 dB(A)
Width1.300 mm
Height230 mm
