803 Wacker Neuson excavator specs & dimensions (2021 - 2026)

Wacker Neuson 803 is a mini excavator manufactured since 2021, with a weight of 0.993 tons. It features a track width of 180 mm, a…

Wacker Neuson 803 is a mini excavator manufactured since 2021, with a weight of 0.993 tons. It features a track width of 180 mm, a transport length of 2.75 meters, a transport width of 0.7 meters, and a transport height of 1.51 meters. The bucket capacity is 0.08 cubic meters. Special equipment includes a blade, rubber track, and track adjustment.

Mini Excavators Wacker Neuson 803

Visit Wacker Neuson live at

Technical specs - 803 Wacker Neuson

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
0.993 t
Transport length
2.75 m
Transport width
0.7 m
Transport height
1.51 m
Bucket capacity
0.08 m³
Track width
180 mm
Driver protection
Ü
Max. Reach horizontal
3.07 m
Dredging depth
1.73 m
Tear-out force
4.5 kN
Model series
800
Engine manuf.
Yanmar
Engine type
3TNV70
Engine power
9.6 kW
Displacement
0.854 l
Revolutions at max torque
2100 rpm
No. of cylinders
3
Emission level
V

More technical details, like: bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
Yes
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Wacker Neuson 803 FAQ

When was the Wacker Neuson 803 manufactured?

The Wacker Neuson 803 was first produced in 2021.

How much does the Wacker Neuson 803 weigh?

The Wacker Neuson 803 weighs 0.99 tons.

What are the transport dimensions of the Wacker Neuson 803 mini excavator?

The Wacker Neuson 803 has a transport length of 2.75 meters, a transport width of 0.7 meters, and a transport height of 1.51 meters.

What is the track width of the Wacker Neuson 803 mini excavator?

The Wacker Neuson 803 mini excavator has a track width of 180 mm.

What are the excavation performance specifications of the Wacker Neuson 803 mini excavator?

The Wacker Neuson 803 mini excavator has a dredging depth of 1.73 meters and a maximum horizontal reach of 3.07 meters.

What is the tear-out force of the Wacker Neuson 803 mini excavator?

The Wacker Neuson 803 mini excavator has a tear-out force of 4.5 kN.

What is the bucket capacity of the Wacker Neuson 803 mini excavator?

The Wacker Neuson 803 mini excavator has a bucket capacity of 0.08 cubic meters.

What operator safety and support features does the Wacker Neuson 803 have?

The Wacker Neuson 803 is equipped with a roll-over bar for driver protection.

How much is a Wacker Neuson 803 Mini excavator (2021u20132025) worth?

The residual value of the Wacker Neuson 803 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
