ECR18E Volvo excavator specs & dimensions (2018 - 2026)

Volvo ECR18E is a mini excavator manufactured since 2018, with a weight of 1.62 tons. It features a track width of 230 mm and has …

Volvo ECR18E is a mini excavator manufactured since 2018, with a weight of 1.62 tons. It features a track width of 230 mm and has transport dimensions of 3.43 meters in length, 0.99 meters in width, and 2.3 meters in height. The machine offers a dredging depth of 2.23 meters and a maximum horizontal reach of 3.92 meters. The bucket capacity is up to 0.36 cubic meters. Special equipment includes a blade and rubber tracks.

Visit Volvo live at

ECR18E

Years of manufacture: 2018—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - ECR18E Volvo

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 1.62 t

Transport length: 3.43 m

Transport width: 0.99 m

Transport height: 2.3 m

Bucket capacity max.: 0.36 m³

Track width: 230 mm

Driver protection: Ü

Max. Reach horizontal: 3.92 m

Dredging depth: 2.23 m

Tear-out force: 7.95 kN

Model series: ECR

Engine manuf.: Volvo

Engine type: D 0.9 A

Engine power: 12 kW

Displacement: 0.898 l

Revolutions at max torque: 2300 rpm

Max. torque: 52/1800 Nm

No. of cylinders: 3

Cylinder bore x stroke: 72x73.6 mm

More technical details, like: bucket capacity, bucket capacity min., bucket width, standard tyres, dimension lxwxh, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: No
Rubber track: Yes
Blade: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Volvo ECR18E FAQ

When was the Volvo ECR18E manufactured?

The Volvo ECR18E was first produced in 2018.

How much does the Volvo ECR18E weigh?

The Volvo ECR18E weighs 1.62 tons.

What are the transport dimensions of the Volvo ECR18E mini excavator?

The Volvo ECR18E has a transport length of 3.43 meters, a transport width of 0.99 meters, and a transport height of 2.3 meters.

What is the track width of the Volvo ECR18E's undercarriage?

The Volvo ECR18E has a track width of 230 mm.

What are the excavation performance specifications of the Volvo ECR18E mini excavator?

The Volvo ECR18E mini excavator has a dredging depth of 2.23 meters and a maximum horizontal reach of 3.92 meters.

What is the tear-out force of the Volvo ECR18E mini excavator?

The Volvo ECR18E mini excavator has a tear-out force of 7.95 kN.

What is the maximum bucket capacity of the Volvo ECR18E mini excavator?

The Volvo ECR18E mini excavator has a maximum bucket capacity of 0.36 cubic meters.

What operator safety feature does the Volvo ECR18E have?

The Volvo ECR18E is equipped with a roll-over bar for driver protection.

How much is a Volvo ECR18E Mini excavator (2018u20132025) worth?

The residual value of the Volvo ECR18E depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Volvo ECR18E overview

Engine / Driveline and transmission

Best-in-class serviceability
Complete speed maintenance tasks thanks to the hinged fuel tank, which gives impressive access to the engine compartment and makes daily check points easy to locate. A 50 hour lubricating interval also contributes to the best serviceability of this machine.
A VOLVO EXCLUSIVE
Best access to the engine compartment thanks to hinged fuel tank A VOLVO EXCLUSIVE, auto engine shutdown and auto-idle (options), 50 hour greasing intervals.

Tyres / Tracks

Compact by design
For superior versatility when working in confined spaces, the ECR18E features an ultra-short rear radius. The machine design ensures that frame corner, swing post and cylinders stay in the tracks while digging alongside obstacles. Result is maximum visibility and a reduced risk of machine damage when working in tight conditions.
Compact by design
Ultrashort swing radius NEW, Variable undercarriage width, less than 1 metre wide, In-track boom swing

Dimensions and weight

	Lifting point height (B) m		2.0 m	Lifting point 3.0 m	Max reach	Max. m

Arm: 950mm + Dozer blade up	2	kg	-	-	-	259	-	251	3.06
1	kg	484*	458	270*	254	265	209	3.44
0	kg	469	434	269	248	220	210	3.40
-1	kg	465*	440	262	-	221	243*	2.93
Arm: 950mm + Dozer blade down	2	kg	-	-	270*	259	274*	251	3.06
1	kg	484*	458	300*	254	261*	209	3.44
0	kg	593*	434	313*	248	248*	210	3.40
-1	kg	465*	440	-	-	243*	243*	2.93
Arm: 950mm + Dozer blade down Heavy counterweight +	2	kg	-	-	270*	271*	274*	266	3.06
1	kg	484*	484	300*	270	261*	222	3.44
0	kg	593*	461	313*	264	248*	224	3.40
-1	kg	465*	467*	-	-	243*	244*	2.93
Arm: 1 150mm + Dozer blade up + Heavy counterweight	2	kg	-	-	228*	228*	244*	239	3.29
1	kg	390*	390*	280*	270	215	204	3.63
0	kg	496	457	277	261	216	205	3.60
-1	kg	497*	459	257*	257*	225*	225*	3.16
Arm: 1 150mm	2	kg	-	-	228*	228*	244*	239	3.29
1	kg	390*	390*	280*	270	239*	204	3.63
+ Dozer blade down	0	kg	603*	457	314*	261	229*	205	3.60
+ Heavy counterweight	-1	kg	497*	459	257*	257*	225*	225*	3.16

Weight and Ground Pressure
Operating weight according to ISO 6016	kg	1 700
Ground pressure (canopy)		kPa	28.4
Transport weight		kg	1 625
With rubber tracks		mm	230
With short arm		mm	950
With fuel tank capacity		%	100
With long arm and heavy counterweight		+kg	42
With steel tracks		+kg	78
Hydraulic system
Maximum system flow		l/min	34
Maximum flow for accessories		l/min	30
Maximum operating pressure		MPa	17
Travel System
Max	drawbar pull"		daN	1 300
Max. travel speed low		km/h	1.8
Max. travel speed high		km/h	3.5
Gradeability		°	30
Service Refill
Fuel tank		l	21
Hydraulic system	total"		l	21
Hydraulic tank		l	15
Sound Level
Interior sound level according to ISO 6396
LpA		dB(A)	78

Description	Unit	ECR18E
Arm		mm	950	1 150
A	Maximum cutting height	mm	3 442	3 582
B	Maximum dump height	mm	2 444	2 588
B*	Maximum bucket clearance		mm	2 482	2 625
C	Digging depth		mm	2 234	2 434
C*	Maximum digging depth		mm	2 528	2 727
D	Maximum vertical wall digging depth		mm	1 898	2 091
E	Maximum digging reach at ground level		mm	3 921	4 113
G	Highest position dozer blade	Short blade	mm		225
		Long blade	mm		267
H	Lowest position dozer blade	Short blade	mm		267
		Long blade	mm		386
J	Track length		mm	1	620
K	Dozer blade	maximum reach at ground level"	Short blade	mm	1	082
		Long blade	mm	1	272
L	Overall width with 230mm tracks	Min	mm		995
		Max	mm	1	352
M	Overall length		mm	3 431	3 309
M*	Transport length (arm lowered)	Short blade	mm	3 932	3 944
		Long blade	mm	4 122	4 134
P	Dozer blade height		mm		231
Q	Shoe width (rubber)		mm		230
Q(1)	Shoe width (steel)		mm		230
R	Ground clearance to superstructure		mm		456
S	Front slew radius		mm	1 575	1 568
T	Front slew radius with maximum offset		mm	1 269	1 287
U*	Overall height canopy		mm	2	298
X	Tail slew radius		mm		688
X*	Rear overhang (across tracks)		mm		12
β1	Maximum boom offset to the right		mm		516
β2 (1)	Maximum boom offset to the left		mm		640

Tables

Engine
Engine		D0.9A
Max. power at	r/min	2 300
Gross	kW	12
	hp	16.3
According to ISO 2534 / SAE J1995
Max. torque	Nm	52
at engine speed	r/min	1 800
No. of cylinders		3
Displacement	cm³	898
Bore	mm	72
Stroke	mm	73.6
Compression ratio		24
Electrical system
Battery	V	1 x 12
Battery capacity	Ah	42 - 70
Alternator	V/Ah	12/40
Swing system
Max	slew speed"	r/min	9.5
Max	slew torque"	daNm	243
Undercarriage
Bottom/top rollers per side		3 / 0
Track tension		By grease piston
Blade (width x height)	mm	1 340 x 230
Digging Performances
Standard bucket width (blade	W/O side cutter)"	mm	450
Standard bucket mass	kg	33
Standard bucket rated capacity	l	36
Bucket rotation	°	196
Bucket breakout force (ISO)	daN	1 290
Short arm tearout force (ISO)	daN	795
Long arm tearout force (ISO)	daN	695
