SWE08B Sunward excavator specs & dimensions (2020 - 2026)

Sunward SWE08B is a mini excavator manufactured since 2020, with a weight of 1.01 tons. It features a track width of 180 mm, a tra…

Sunward SWE08B is a mini excavator manufactured since 2020, with a weight of 1.01 tons. It features a track width of 180 mm, a transport length of 2.64 meters, a transport width of 0.75 meters, and a transport height of 2.25 meters. The machine has a tear-out force of 9.4 kN, a dredging depth of 1.83 meters, and a maximum horizontal reach of 3.18 meters. The bucket width is 0.32 meters with a capacity of 0.02 cubic meters. Special equipment includes a blade and rubber tracks.

SWE08B

Years of manufacture: 2020—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - SWE08B Sunward

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 1.01 t

Transport length: 2.64 m

Transport width: 0.75 m

Transport height: 2.25 m

Bucket capacity: 0.02 m³

Bucket width: 0.32 m

Track width: 180 mm

Driver protection: FD

Max. Reach horizontal: 3.18 m

Dredging depth: 1.83 m

Tear-out force: 9.4 kN

Model series: SWE

Engine manuf.: Yanmar

Engine type: 2TNV70PSU

Engine power: 7.2 kW

Displacement: 0.57 l

Revolutions at max torque: 2400 rpm

No. of cylinders: 2

Emission level: V

More technical details, like: bucket capacity min., bucket capacity max., standard tyres, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: No
Rubber track: Yes
Blade: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Sunward SWE08B FAQ

When was the Sunward SWE08B manufactured?

The Sunward SWE08B was first produced in 2020.

How much does the Sunward SWE08B mini excavator weigh?

The Sunward SWE08B mini excavator weighs 1.01 tons.

What are the transport dimensions of the Sunward SWE08B mini excavator?

The Sunward SWE08B mini excavator has a transport length of 2.64 meters, a transport width of 0.75 meters, and a transport height of 2.25 meters.

What is the track width of the Sunward SWE08B mini excavator's undercarriage?

The Sunward SWE08B mini excavator has a track width of 180 mm.

What are the excavation performance specifications of the Sunward SWE08B mini excavator?

The Sunward SWE08B mini excavator has a dredging depth of 1.83 meters and a maximum horizontal reach of 3.18 meters.

What is the tear-out force of the Sunward SWE08B mini excavator?

The Sunward SWE08B mini excavator has a tear-out force of 9.4 kN.

What are the bucket specifications of the Sunward SWE08B mini excavator?

The Sunward SWE08B has a bucket capacity of 0.02 cubic meters and a bucket width of 0.32 meters.

What operator safety feature does the Sunward SWE08B have?

The Sunward SWE08B has a canopy for driver protection.

How much is a Sunward SWE08B Mini excavator (2020u20132025) worth?

The residual value of the Sunward SWE08B depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Sunward SWE08B overview

Sunward SWE08B features overview

Telescopic chassis
Controlled by simple single joystick, the chassis width can be retracted to 750mm to adapt to tight spaces. On the counter y, the chassis width can be extended up to 1,000mm to improve stability by 15% a n d e v e n a l o w t h u s e f h y d r a u l i c break-

Engine / Driveline and transmission

Yanmar engine
This engine is confident on compact equipment and features low noise, low vibration as well as easy maintenance for main parts.

Hydraulics

Pilot control for working device
The hydraulic pilot control is first applied for the work d e v i c e, f e a t u r i n g b et t e r accuracy and smoothness.
Working device pipeline
The transition linkage is applied to all work piping on the boom root to facilitate repairs and replacement, and any exposed pipelines at risk from collision or scratches are protected by steel sleeves to effectively extend service life.

Dimensions and weight

SWE08B Technical Parameters
Type of cab	Open cab
Bucket capacity	std."	m³	0.022
Bucket width	mm	320
Machine weight	kg	1010
Dimensions	Overall length	mm	2640
Overall height	mm	2250
Overall width	mm	750
Ground clearance	mm	131
Engine	Brand		Yanmar
Model	2TNV70-PSU
Displacement	L	0.57
Output	kW/rpm	7.2/2400
Working ranges	Max cutting height	mm	3085
Max loading height	mm	2305
Max digging depth	mm	1825
Max digging reach	mm	3180
Boom swing angle（left/right）	°	73/53
Front swing radius	mm	1221
Tail swing radius	mm	750
Max digging force（Arm）	kN	5.8
Max digging force（Bucket）	kN	9.4
Track	Type		Rubber crawler
Rubber shoe Width	mm	180
Undercarrige	Track Length	mm	1299
Length to center of Rollers	mm	975
Lenhth to center of track	mm	560/820
Travelling spaeed（High/Low）	km/h	2.9/1.5
Gradeability	deg	30
Swing speed		rpm	8.2
Ground pressure	kpa	24.5
Dozer size	Width	mm	750/1000
Height	mm	190
Lifting capacity（Height/Depth）	mm	225/225
Hydraulic pumps	Type		3 Gear pump
Flow rate	L/min	3*9.6
Hydraulic pressure	Mpa	2*16
Swing motor			Cycloidal motor
Travel motor		2-speed ram motor
Fuel tank capacity	L	10
Hydraulic oil tank capacity	L	9.5

Other features

Quick change device
It can allow the removal and installation of different buckets and attachments to be time-saving and rapid.

Safety

Fops/Tops
T h e s t a n d a r d t i l t a b l e / f o l d a b l e Protective cage complies with EU F o p s / T o p s A f e t y c e r v i k a t i o n to protect the driver. This protective cage features better roadability after folding.
Hoisting points
3 lifting points with high safety and simplicity are provided for direct h o i s t i n g a n d r a n s p o r t b y a c r a n e.

Tables

Lift Point Height	Lift Point Radius(MAX)	Lift Point Radius(2.0m)	Lift Point Radius(1.0m)
Over-front(kg)	Over-side(kg)	Over-front(kg)	Over-side(kg)	Over-front(kg)	Over-side(kg)
2.0m	119.60*	86.6	129.20*	107.30	-	-
1.0m	157.90*	61.9	100.50*	94.90	416.40*	264.00
0.0m	196.20*	70.1	224.90*	86.60	445.10*	202.20
-1.0m	205.80*	127.9	-	-	287.10*	243.40
