REX18 RHINO excavator specs & dimensions (2017 - 2026)

RHINO REX18 is a Mini Excavator manufactured since 2017, with a weight of 1.76 t. It features a track width of 230 mm, a transport…

RHINO REX18 is a Mini Excavator manufactured since 2017, with a weight of 1.76 t. It features a track width of 230 mm, a transport length of 2.38 m, a transport width of 1.1 m, and a transport height of 2.247 m. The machine has a tear-out force of 11.4 kN, a dredging depth of 1.98 m, and a maximum horizontal reach of 3.64 m. The bucket capacity is a minimum of 0.04 m³. Special equipment includes a blade and rubber track.

Mini Excavators RHINO REX18

Technical specs - REX18 RHINO

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.76 t
Transport length
2.38 m
Transport width
1.1 m
Transport height
2.247 m
Bucket capacity min.
0.04 m³
Track width
230 mm
Driver protection
FD
Max. Reach horizontal
3.64 m
Dredging depth
1.98 m
Tear-out force
11.4 kN
Model series
REX

More technical details, like: bucket capacity, bucket capacity max., bucket width, standard tyres, engine manuf., engine type, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders...

More technical details, like: bucket capacity, bucket capacity max., bucket width, standard tyres, engine manuf., engine type, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

RHINO REX18 FAQ

When was the RHINO REX18 manufactured?

The RHINO REX18 was first produced in 2017.

How much does the RHINO REX18 weigh?

The RHINO REX18 weighs 1.76 tons.

What are the transport dimensions of the RHINO REX18 mini excavator?

The RHINO REX18 has a transport length of 2.38 meters, a transport width of 1.1 meters, and a transport height of 2.25 meters.

What is the track width of the RHINO REX18 mini excavator?

The RHINO REX18 mini excavator has a track width of 230 mm.

What are the dredging depth and maximum horizontal reach of the RHINO REX18 mini excavator?

The RHINO REX18 mini excavator has a dredging depth of 1.98 meters and a maximum horizontal reach of 3.64 meters.

What is the tear-out force of the RHINO REX18 mini excavator?

The RHINO REX18 mini excavator has a tear-out force of 11.4 kN.

What is the minimum bucket capacity of the RHINO REX18 mini excavator?

The RHINO REX18 mini excavator has a minimum bucket capacity of 0.04 cubic meters.

What operator safety and support features does the RHINO REX18 have?

The RHINO REX18 is equipped with a canopy for driver protection.

How much is a RHINO REX18 Mini excavator (2017u20132025) worth?

The residual value of the RHINO REX18 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
