EC15 New Holland excavator specs & dimensions (1999 - 2026)

New Holland EC15 is a mini excavator manufactured since 1999, with a weight of 1 ton. It features a track width of 230 mm, a trans…

New Holland EC15 is a mini excavator manufactured since 1999, with a weight of 1 ton. It features a track width of 230 mm, a transport length of 3 meters, a transport width of 0.99 meters, and a transport height of 2 meters. The maximum bucket capacity is 2 cubic meters. Special equipment includes a blade and rubber tracks.

Mini Excavators New Holland EC15

Technical specs - EC15 New Holland

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1 t
Transport length
3 m
Transport width
0.99 m
Transport height
2 m
Bucket capacity max.
2 m³
Track width
230 mm
Driver protection
Ü
Max. Reach horizontal
3.9 m
Dredging depth
2.2 m
Tear-out force
13.3 kN
Engine manuf.
Mitsubishi
Engine type
L3E.61KL
Engine power
13.3 kW
Displacement
0.952 l
No. of cylinders
3

More technical details, like: bucket capacity, bucket capacity min., bucket width, standard tyres, model series, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

New Holland EC15 FAQ

When was the New Holland EC15 manufactured?

The New Holland EC15 was first produced in 1999.

How much does the New Holland EC15 weigh?

The New Holland EC15 weighs 1 ton.

What are the transport dimensions of the New Holland EC15 mini excavator?

The New Holland EC15 mini excavator has a transport length of 3 meters, a transport width of 0.99 meters, and a transport height of 2 meters.

What is the track width of the New Holland EC15 mini excavator?

The New Holland EC15 mini excavator has a track width of 230 mm.

What are the excavation performance specifications of the New Holland EC15 mini excavator?

The New Holland EC15 mini excavator has a dredging depth of 2.2 meters and a maximum horizontal reach of 3.9 meters.

Is there any power rating data available for the New Holland EC15 mini excavator?

The available data does not include any power ratings for the New Holland EC15 mini excavator.

What is the maximum bucket capacity of the New Holland EC15 mini excavator?

The New Holland EC15 mini excavator has a maximum bucket capacity of 2 cubic meters.

What operator safety and support features does the New Holland EC15 have?

The New Holland EC15 is equipped with a roll-over bar for driver protection.

How much is a New Holland EC15 Mini excavator (1999u20132025) worth?

The residual value of the New Holland EC15 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
