E19C New Holland excavator specs & dimensions (2017 - 2021)

Right for your needs.
Many business operations have a need for a loader that provides versatility to move much more than just bulk material. Typical alternative applications include entering and balancing, the ability to grab heavy-duty items such as suitcase rams and concreating pillars, plus a tractor unit with traction and force pushing materials or objects into their way or out of its way. Featuring a 4 in 1 bucket, a backhoe loader delivers this exceptional performance with only the single attachment. Choose a 6in1 bucket and you'll have the option of tilting down adjustable pallet forks, ideal for handling palletized loads without using your own vehicle. The backhoe can be equipped with a wide choice of shovels so digs, water parallel clearance, trenches and other requirements are matched each other. Posthole drill bits, hydraulic hammers and countless other tools can all be fitted. The long range of both standard and telescopic dipper up to a massive 6965mm allows large reach and digging depth comparable to many conventional dedivided excavators.
Welcome aboard.
A good cabin offers good operator comfort, excellent ergonomics and plenty of room for quick shifting between loader and backhoe operation. A large cab combines this with superb all-round visibility, top class heating and ventilation with low noise levels and vibration level. With the newly updated Cab on New Holland rear shoe loaders you get all small additional details that make the cab an extra special. Room for tools and curiosities as well as personal items. A high grip floor covering to prevent slipping when entering through muddy shoes. A powerful lighting package featuring up to ten optional LED lights gives a true 360 degree light image thanks to the canopy mounted side lights. Large lockable sunshades, cup holder, glove box and deluxe pneumatic heated seat area. To meet has been relocated the engine exhaust pipe to the right in order to provide a clear view onto the loading arm. Improved in-cab storage, Spacious Cabin allows easy seat transition into operation The choice of entrance plane mechanically and deluxehed is available POWER MACHINES (CQF) have proven to be able to deliver better views over timepiece performance than CHOXA: Low output power supply points are provided by handheld hydraulically controlled front panels which give riser protection against air pressure at any angle or other surfaces where it's need not only work properly
Backhoe
Standard features include: Curved arm design for easier loading over trailer sides and obstacles, Durable swings with ground level greasing points, Wide cushion stabilisers with adjustable foot guidance, Powerful bucket and dipper breakout for optimum performance The choice of Key Backhoe specification options includes: Fixed or extendible dipper arm option - fixed dipper offers 4710mm digging depth - telescopic dipper extends dig depth to 5785mm, solid media or hydraulic sideshift capability, direct adjustment or quick coupler shell selection, Object Handling Kit available. EU certified for handling hanging objects offer conventional pilot controls for the back pantsin good feedback and response through the hydraulics, With full proportional control Pilotbackhoe Control joysticks are fully adjustable, selectable ISO respectively SAE operating patterns add object handle kit Lift hooks, safety valves both to boom as well as dipper and overload protection, Hydraulic side shift allows precise positioning of the rear shoe allowing the operator to optimize shovel view when digging an obstacle is not possible but also optimises
Trained to give you the best support
Your dedicated New Holland dealer technicians receive regular training updates. These are conducted through both online courses and intensive classroom sessions. This advanced approach ensures that your dealer always has the skills needed to take care of New Holland's latest and most modern products.

The models described herein may be modified without prior notice by the manufacturer. Drawings and photos may refer to equipment that is optional or intended for other countries. For further information, please contact our sales network. Published by New Holland Brand Communications. Bts Adv. - Printed in Italy - 06/19 - (Turin) - 194000/INB

In-built versatility.
New Holland backhoe loaders are your versatile choice for loading, sorting, grappling, lifting, excavating, digging, planting, post hole drilling and, well the list goes on. Businesses ranging from agriculture to horticulture, landscaping up to drainage and irrigation require diverse and cost-effective equipment. A backhoe loader gives loader and backhoe specification options. The B115 C allwheel steer has powerful performance in challenging conditions with no compromises on agility. Beginner models of level B100 C are affordable but available with a high standard specifi cation for a wide range of needs. Available through selected New Holland Agriculture dealers, the latest C Series backhoe loader is an investment that never comes too short. Maintained seat Fixed or extendable backhoe Dipper Backhoe Craning capacity up to 1423kg Fixed or lateral changing backhoe Four wheel drive as standard with selectable two wheel drive Mechanical Power shuttle Or automatic powershift shift capability Up to 1423kg Fixed or lateral shifting backhoe 4x4 kg 4-wheel drive With selectable dual wheel drive Mechanical Power Shuttle

Up x10 LED working lights class leading in-cab noise level matched to proven New Holland ergonomics Excellent all round visibility Tier 4B F5H 3.4 liter four cylinder engine TC Tool Carrier Front loader Three steering modes on the same wheel B115 C Up to 3.5 tonnes lifting capacity.
Powershift™ or powershuttle, you decide.
New Holland offers its backhoe loaders with switchable two or four wheel drive, a Powershuttle Forward / Reverse mechanical transmission or automatic power change gear. the all-wheel steer b115 c has equally large front and rear wheels with selectable front, All-wheel and crab steering modes.
Steering column mounted lever for shuttle and speed
Four gears with incorporated transmission decoupling button, fully modulated gear shift with speed tuned electro-hydraulic forward/reverseShuttle, Affordable, reliable and easy to operate, Ideal choice where the backhoe sees more use than front in shifting lever loader selection and vice versa, Easy usage matched to low maintenance needs, Ideal transmission option for extensive front loader tasks, Loader joystick with transmission decoupling knob for diverting full power to hydraulics depending on demand, Selectable two or four wheel drive.
Four-wheel steer B115 C
The new Holland B115 C models can be operated in one of three steering modes: Conventional front wheel steering is ideal for normal loading and transport applications, all-wheel steer delivers excellent manoeuvrability with no impact on stability, Crablenker is ideally suited to working close to a trench or obstacle and can be useful when working over sensitive terrain to reduce trade, the B115 C all-wheel steer provides excellent traction with limited slip differentials both front and rear. Power is automatically diverted under adverse conditions – without needing operator input; self adjusting oil immersed disc brakes are designed to provide reliable performance. Mounted within the reduction hubs, braking can easily be maintained without having to strip the axle.
Powerful economy.
The model-dependent FPT Industrial F5H 3.4 litre four cylinder engine in backhoe loaders develops 98, 111hp and is the same unit as on New Holland T5 tractors. Complain with stringent Tier 4B emission regulations, the engines feature an advanced gas control system. This allows the operator to set how the engine reacts to throttle inputs from smooth to fast.
Compact hi-escr after-treatment emission system
The New Holland sister company FPT Industrial has designed the engine F5H to meet tough emission regulations without needing a diesel particulate filter. By combining proven Selective Catalytic Conversion with Exhaust Gas Recirculation, an F5H engine can be operated for longer periods at low loads without having to regenerate blocking of a DPF filter. 98 and 111hp output selection, new side-by-side mounting for exhaust stacks for improved visibility, engine shut-off protection in case of low oil pressure plus high coolant or transmission oil temperatures, 132 liter fuel as well as 42 litre adblue capacity, Three gas settings, soft, normal and fast are offered.

Hydraulics to meet every demand.
To meet the needs of the end user accurately, New Holland backhoe loaders are offered with a choice of hydraulic pump designs. In addition, an auxiliary hydraulic circuit is available for attachments that includes hydraulic breaker and ground augers.
Twin gear pump
Simple, constant flow, Quick warm up, Straight line service and maintenance, For general use. Adapted to applications with limited travel path, Maximum flow 151l/min @ 2200rpm, Maximum operating pressure 205bar
Variable displacement pump
Only active when there is demand for oil, flow rate proportional to demand, Reduces fuel consumption, Reduced oil temperature by fl ow on demand, Ideal for intensive backhoe operation and frequent roading, Variable flow from 6 to 165l/min, Maximum operating pressure 205bar, A variable displacement hydraulic pump delivers a flow only if needed; saving fuel while driving the road and in applications such as dozing and grading.

An optional auxiliary hydraulic circuit delivers 0-135l/min, Ideal for working ground augers, large grapples and hydraulic breakers.

Chassis
All backhoe models benefit from a fullframe chassis whose exceptional strength dissipates all stresses through the robust frame without load on the engine or transmission. Robot welded the full length frame chassis, no stress to the engine or transmission, plate reinforced stress points, casting backhoe slider interface, open design for ease of maintenance.
Spend time saving money.
A key to equipment performance and durability is routine care. New Holland has developed the backhoe loader, so it takes the minimum of time for carrying out routine checks. Service intervals are also fixed at 600 and 1000 hours, with easy access to all major fuel, engine, transmission and hydraulic filters. Extensive New Holland dealer net for full support is always on hand. One piece hood for full engine access, All main daily checks grouped together, battery shutdown and remote jump start terminals easily accessible, All decisive greasing points on the loader and backhoe have ground-level access, Providing key service items from ground level makes the job easier, faster and safer, maintenance free disc brakes are standard features.
