E16B New Holland excavator specs & dimensions (2008 - 2015)

New Holland E16B is a mini excavator manufactured from 2008 to 2015. It has a weight of 1.52 tons and a track width of 230 mm. The…

New Holland E16B is a mini excavator manufactured from 2008 to 2015. It has a weight of 1.52 tons and a track width of 230 mm. The transport dimensions are 3.65 meters in length, 0.99 meters in width, and 2.34 meters in height. The bucket capacity ranges from a minimum of 0.028 cubic meters to a maximum of 0.069 cubic meters. Special equipment includes a blade and rubber tracks.

Mini Excavators New Holland E16B
Mini Excavators New Holland E16B
Mini Excavators New Holland E16B
Mini Excavators New Holland E16B

Technical specs - E16B New Holland

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.52 t
Transport length
3.65 m
Transport width
0.99 m
Transport height
2.34 m
Bucket capacity min.
0.028 m³
Bucket capacity max.
0.069 m³
Track width
230 mm
Driver protection
FD
Max. Reach horizontal
3.99 m
Dredging depth
2.38 m
Tear-out force
8.7 kN
Model series
E
Engine manuf.
Mitsubishi
Engine type
L 3 E-W 231 KBS
Engine power
11.2 kW
Displacement
1.01 l
Revolutions at max torque
2100 rpm

More technical details, like: bucket capacity, bucket width, standard tyres, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

New Holland E16B FAQ

When was the New Holland E16B manufactured?

The New Holland E16B was manufactured from 2008 to 2015.

How much does the New Holland E16B mini excavator weigh?

The New Holland E16B mini excavator weighs 1.52 tons.

What are the transport dimensions of the New Holland E16B mini excavator?

The New Holland E16B has a transport length of 3.65 meters, a transport width of 0.99 meters, and a transport height of 2.34 meters.

What is the track width of the undercarriage on the New Holland E16B mini excavator?

The New Holland E16B mini excavator has a track width of 230 mm.

What is the excavation performance of the New Holland E16B mini excavator?

The New Holland E16B mini excavator has a dredging depth of 2.38 meters and a maximum horizontal reach of 3.99 meters.

What is the tear-out force of the New Holland E16B mini excavator?

The New Holland E16B mini excavator has a tear-out force of 8.7 kN.

What are the bucket capacity specifications of the New Holland E16B mini excavator?

The New Holland E16B mini excavator has a bucket capacity ranging from 0.03 to 0.07 cubic meters.

What operator safety and support features does the New Holland E16B have?

The New Holland E16B is equipped with a canopy for driver protection.

How much is a New Holland E16B Mini excavator (2008u20132015) worth?

The residual value of the New Holland E16B depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
