NR 2.6 Neumeier excavator specs & dimensions (2006 - 2010)

Neumeier NR 2.6 is a mini excavator manufactured from 2006 to 2010, with a weight of 2.65 tons. It features a track width of 300 m…

Neumeier NR 2.6 is a mini excavator manufactured from 2006 to 2010, with a weight of 2.65 tons. It features a track width of 300 mm, a transport length of 4.51 meters, a transport width of 1.45 meters, and a transport height of 2.47 meters. The bucket capacity is 0.12 cubic meters. Special equipment includes air conditioning, a blade, and rubber tracks.

NR 2.6

Years of manufacture: 2006—2010

Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - NR 2.6 Neumeier

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.65 t

Transport length: 4.51 m

Transport width: 1.45 m

Transport height: 2.47 m

Bucket capacity: 0.12 m³

Track width: 300 mm

Driver protection: Kb

Max. Reach horizontal: 4.6 m

Dredging depth: 2.61 m

Tear-out force: 28.2 kN

Model series: NR

Engine manuf.: Cummins

Engine type: A1400

Engine power: 24 kW

More technical details, like: bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: No
Rubber track: Yes
Blade: Yes
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Neumeier NR 2.6 FAQ

When was the Neumeier NR 2.6 manufactured?

The Neumeier NR 2.6 was manufactured from 2006 to 2010.

How much does the Neumeier NR 2.6 weigh?

The Neumeier NR 2.6 weighs 2.65 tons.

What are the transport dimensions of the Neumeier NR 2.6 mini excavator?

The Neumeier NR 2.6 has a transport length of 4.51 meters, a transport width of 1.45 meters, and a transport height of 2.47 meters.

What is the track width of the Neumeier NR 2.6 mini excavator?

The Neumeier NR 2.6 mini excavator has a track width of 300 mm.

What are the excavation performance specifications of the Neumeier NR 2.6 mini excavator?

The Neumeier NR 2.6 mini excavator has a dredging depth of 2.61 meters and a maximum horizontal reach of 4.6 meters.

What is the tear-out force of the Neumeier NR 2.6 mini excavator?

The Neumeier NR 2.6 mini excavator has a tear-out force of 28.2 kN.

What is the bucket capacity of the Neumeier NR 2.6 mini excavator?

The Neumeier NR 2.6 mini excavator has a bucket capacity of 0.12 cubic meters.

What operator safety and support features does the Neumeier NR 2.6 have?

The Neumeier NR 2.6 has a cabin for driver protection.

How much is a Neumeier NR 2.6 Mini excavator (2006u20132010) worth?

The residual value of the Neumeier NR 2.6 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
