NT08 Nante excavator specs & dimensions (2017 - 2020)

Nante NT08 is a mini excavator manufactured from 2017 to 2020. It has a weight of 0.87 tons and a track width of 190 mm. The trans…

Nante NT08 is a mini excavator manufactured from 2017 to 2020. It has a weight of 0.87 tons and a track width of 190 mm. The transport dimensions are 2.817 meters in length, 1.49 meters in width, and 0.82 meters in height. The machine features a tear-out force of 9.6 kN, a dredging depth of 1.497 meters, and a maximum horizontal reach of 2.7 meters. The bucket capacity is 0.022 cubic meters, and it is equipped with a blade.

Mini Excavators Nante NT08

Technical specs - NT08 Nante

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
0.87 t
Transport length
2.817 m
Transport width
1.49 m
Transport height
0.82 m
Bucket capacity max.
0.022 m³
Track width
190 mm
Driver protection
Ü/FD/O
Max. Reach horizontal
2.7 m
Dredging depth
1.497 m
Tear-out force
9.6 kN
Engine manuf.
Yanmar
Engine type
2TNV70
Engine power
7.4 kW

More technical details, like: bucket capacity, bucket capacity min., bucket width, standard tyres, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
No
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Nante NT08 FAQ

When was the Nante NT08 manufactured?

The Nante NT08 was manufactured from 2017 to 2020.

How much does the Nante NT08 mini excavator weigh?

The Nante NT08 mini excavator weighs 0.87 tons.

What are the transport dimensions of the Nante NT08 mini excavator?

The Nante NT08 mini excavator has a transport length of 2.82 meters, a transport width of 1.49 meters, and a transport height of 0.82 meters.

What is the track width of the Nante NT08 mini excavator?

The Nante NT08 mini excavator has a track width of 190 mm.

What are the excavation performance specifications of the Nante NT08 mini excavator?

The Nante NT08 mini excavator has a dredging depth of 1.497 meters and a maximum horizontal reach of 2.7 meters.

What is the tear-out force of the Nante NT08 mini excavator?

The Nante NT08 mini excavator has a tear-out force of 9.6 kN.

What is the maximum bucket capacity of the Nante NT08 mini excavator?

The Nante NT08 mini excavator has a maximum bucket capacity of 0.02 cubic meters.

What operator safety and support features does the Nante NT08 mini excavator have?

The Nante NT08 mini excavator offers driver protection options including canopy, roll-over bar, or no protection.
