M 16 BV Messersi excavator specs & dimensions (1995 - 2004)

Messersi M 16 BV is a mini excavator manufactured from 1995 to 2004, with a weight of 1.63 tons. It features a track width of 230 …

Messersi M 16 BV is a mini excavator manufactured from 1995 to 2004, with a weight of 1.63 tons. It features a track width of 230 mm and a transport width of 1.015 meters. The bucket capacity is a minimum of 0.036 cubic meters. Special equipment includes a blade and rubber tracks.

Mini Excavators Messersi M 16 BV

Technical specs - M 16 BV Messersi

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.63 t
Transport width
1.015 m
Bucket capacity min.
0.036 m³
Track width
230 mm
Driver protection
KbR
Model series
M
Engine manuf.
Perkins
Engine type
103-10
Engine power
14 kW
Displacement
1 l
Revolutions at max torque
2300 rpm

More technical details, like: transport length, transport height, bucket capacity, bucket capacity max., bucket width, standard tyres, max. reach horizontal, dredging depth, tear-out force, dimension lxwxh, max. torque, no. of cylinders...

More technical details, like: transport length, transport height, bucket capacity, bucket capacity max., bucket width, standard tyres, max. reach horizontal, dredging depth, tear-out force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Messersi M 16 BV FAQ

When was the Messersi M 16 BV manufactured?

The Messersi M 16 BV was manufactured from 1995 to 2004.

How much does the Messersi M 16 BV weigh?

The Messersi M 16 BV weighs 1.63 tons.

What is the transport width of the Messersi M 16 BV mini excavator?

The transport width of the Messersi M 16 BV mini excavator is 1.02 meters.

What is the track width of the Messersi M 16 BV mini excavator?

The Messersi M 16 BV mini excavator has a track width of 230 mm.

What is the minimum bucket capacity of the Messersi M 16 BV mini excavator?

The minimum bucket capacity of the Messersi M 16 BV mini excavator is 0.04 cubic meters.

What operator safety features does the Messersi M 16 BV have?

The Messersi M 16 BV is equipped with a cabin that includes ROPS (Roll-Over Protective Structure) for driver protection.

How much is a Messersi M 16 BV Mini excavator (1995u20132004) worth?

The residual value of the Messersi M 16 BV depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
