KX41-2 Kubota excavator specs & dimensions (1997 - 2026)

Kubota KX41-2 is a mini excavator manufactured since 1997, with a weight of 1.67 tons. It has a transport length of 3.57 meters, a…

Kubota KX41-2 is a mini excavator manufactured since 1997, with a weight of 1.67 tons. It has a transport length of 3.57 meters, a transport width of 1.005 meters, and a transport height of 2.35 meters. The dredging depth is 2.335 meters, and the maximum horizontal reach is 3.8 meters.

Mini Excavators Kubota KX41-2

Technical specs - KX41-2 Kubota

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.67 t
Transport length
3.57 m
Transport width
1.005 m
Transport height
2.35 m
Max. Reach horizontal
3.8 m
Dredging depth
2.335 m
Engine manuf.
Kubota
Engine type
D1105-BH-7
Engine power
16.1 kW
Displacement
1.123 l
Revolutions at max torque
2400 rpm
No. of cylinders
3

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, track width, standard tyres, driver protection, tear-out force, model series, dimension lxwxh, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
No
Blade
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Kubota KX41-2 FAQ

When was the Kubota KX41-2 manufactured?

The Kubota KX41-2 was first produced in 1997.

How much does the Kubota KX41-2 weigh?

The Kubota KX41-2 weighs 1.67 tons.

What are the transport dimensions of the Kubota KX41-2 mini excavator?

The Kubota KX41-2 has a transport length of 3.57 meters, a transport width of 1.01 meters, and a transport height of 2.35 meters.

What are the dredging depth and maximum horizontal reach of the Kubota KX41-2 mini excavator?

The Kubota KX41-2 mini excavator has a dredging depth of 2.335 meters and a maximum horizontal reach of 3.8 meters.

How much is a Kubota KX41-2 Mini excavator (1997u20132025) worth?

The residual value of the Kubota KX41-2 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Machine inspection

Ask for inspection of your Kubota KX41-2 from experts

Machine inspection

Mevas is an international operating inspection service for used heavy machinery. Construction machinery inspectors are available in more than 20 countries.

Use this service to minimise the risk when buying used equipment. An inspection by Mevas costs less than repairing a defective hydraulic cylinder.

Enquire machine inspection

Provided by: Mevas — The Heavy Equipment Inspectors

Buy & Rent

Mini Excavator Buyers Guide - price ranges of new and used models

At LECTURA we check price lists since 40 years and using this data, we can support sellers with price lists of used mini excavators, such as Kubota KX41-2.

Check what new and used models of mini excavators you can get in each price range:

Data provided by Lectura logo

Compare Kubota KX41-2 with similar Mini Excavators

Kubota KX41-2

Kubota KX41-2

Weight:
1.67 t
Transport length:
3.57 m
Transport width:
1.005 m
Transport height:
2.35 m
Wacker Neuson ET 18

Wacker Neuson ET 18

Weight:
1.74 t
Transport length:
3.8 m
Transport width:
0.99 m
Transport height:
2.29 m
Caterpillar 301.7D

Caterpillar 301.7D

Weight:
1.72 t
Transport length:
3.855 m
Transport width:
0.99 m
Transport height:
2.29 m
JCB 801

JCB 801

Weight:
1.43 t
Transport width:
0.98 m
