KX019-4 HGL Kubota excavator specs & dimensions (2022 - 2026)

Kubota KX019-4 HGL is a mini excavator manufactured since 2022, with a weight of 1.775 tons. It features a track width of 230 mm a…

Kubota KX019-4 HGL is a mini excavator manufactured since 2022, with a weight of 1.775 tons. It features a track width of 230 mm and has transport dimensions of 3.86 meters in length, 1.3 meters in width, and 2.33 meters in height. The excavator is equipped with a bucket width of 0.45 meters and a bucket capacity of 0.04 cubic meters. Special equipment includes a blade, rubber track, and track adjustment.

Mini Excavators Kubota KX019-4 HGL
Mini Excavators Kubota KX019-4 HGL
Mini Excavators Kubota KX019-4 HGL
Mini Excavators Kubota KX019-4 HGL

Technical specs - KX019-4 HGL Kubota

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.78 t
Transport length
3.86 m
Transport width
1.3 m
Transport height
2.33 m
Bucket capacity
0.04 m³
Bucket capacity max.
0.04 m³
Bucket width
0.45 m
Track width
230 mm
Driver protection
FD
Max. Reach horizontal
4.12 m
Dredging depth
2.58 m
Tear-out force
16.2 kN
Engine manuf.
Kubota
Engine type
D902-BH
Engine power
11.8 kW
Displacement
0.898 l
Revolutions at max torque
2300 rpm
No. of cylinders
3
Cylinder bore x stroke
72x7.3.6 mm
Emission level
V

More technical details, like: bucket capacity min., standard tyres, model series, dimension lxwxh, max. torque are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
Yes
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Kubota KX019-4 HGL FAQ

When was the Kubota KX019-4 HGL manufactured?

The Kubota KX019-4 HGL was first produced in 2022.

How much does the Kubota KX019-4 HGL weigh?

The Kubota KX019-4 HGL weighs 1.78 tons.

What are the transport dimensions of the Kubota KX019-4 HGL mini excavator?

The Kubota KX019-4 HGL has a transport length of 3.86 meters, a transport width of 1.3 meters, and a transport height of 2.33 meters.

What is the track width of the Kubota KX019-4 HGL mini excavator?

The Kubota KX019-4 HGL mini excavator has a track width of 230 mm.

What are the excavation performance specifications of the Kubota KX019-4 HGL mini excavator?

The Kubota KX019-4 HGL mini excavator has a dredging depth of 2.58 meters and a maximum horizontal reach of 4.12 meters.

What are the power ratings of the Kubota KX019-4 HGL mini excavator?

There are no power rating specifications available for the Kubota KX019-4 HGL mini excavator in the provided data.

What are the bucket specifications of the Kubota KX019-4 HGL mini excavator?

The Kubota KX019-4 HGL has a bucket capacity of 0.04 cubic meters, a maximum bucket capacity of 0.04 cubic meters, and a bucket width of 0.45 meters.

What operator safety feature does the Kubota KX019-4 HGL have?

The Kubota KX019-4 HGL is equipped with a canopy for driver protection.
