KH90 Kubota excavator specs & dimensions (1984 - 2026)

Kubota KH90 is a mini excavator manufactured since 1984, with a weight of 3.3 tons. It has a transport length of 4.915 meters, a t…

Kubota KH90 is a mini excavator manufactured since 1984, with a weight of 3.3 tons. It has a transport length of 4.915 meters, a transport width of 1.51 meters, and a transport height of 2.37 meters. The dredging depth is 3.05 meters, and the maximum horizontal reach is 4.905 meters. The bucket width is 0.58 meters, and the bucket capacity is 0.15 cubic meters.

Mini Excavators Kubota KH90

Technical specs - KH90 Kubota

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.3 t
Transport length
4.915 m
Transport width
1.51 m
Transport height
2.37 m
Bucket capacity
0.15 m³
Bucket width
0.58 m
Driver protection
Kb
Max. Reach horizontal
4.905 m
Dredging depth
3.05 m
Engine manuf.
Kubota
Engine type
V1702-BH
Engine power
34.7 HP
Displacement
1.732 l
Revolutions at max torque
2400 rpm
No. of cylinders
4

More technical details, like: bucket capacity min., bucket capacity max., track width, standard tyres, tear-out force, model series, dimension lxwxh, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
No
Blade
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Kubota KH90 FAQ

When was the Kubota KH90 manufactured?

The Kubota KH90 was first produced in 1984.

How much does the Kubota KH90 mini excavator weigh?

The Kubota KH90 mini excavator weighs 3.3 tons.

What are the transport dimensions of the Kubota KH90 mini excavator?

The Kubota KH90 has a transport length of 4.92 meters, a transport width of 1.51 meters, and a transport height of 2.37 meters.

What are the excavation performance specifications of the Kubota KH90 mini excavator?

The Kubota KH90 mini excavator has a dredging depth of 3.05 meters and a maximum horizontal reach of 4.905 meters.

What are the bucket specifications of the Kubota KH90 mini excavator?

The Kubota KH90 mini excavator has a bucket capacity of 0.15 cubic meters and a bucket width of 0.58 meters.

What operator safety and support features does the Kubota KH90 have?

The Kubota KH90 provides operator safety through a protective cabin.

How much is a Kubota KH90 Mini excavator (1984u20132025) worth?

The residual value of the Kubota KH90 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
