KH41 Kubota excavator specs & dimensions (1988 - 2026)

Kubota KH41 is a mini excavator manufactured since 1988, with a weight of 1.525 tons. It features a track width of 230 mm, a trans…

Kubota KH41 is a mini excavator manufactured since 1988, with a weight of 1.525 tons. It features a track width of 230 mm, a transport length of 3.485 meters, a transport width of 0.98 meters, and a transport height of 2.22 meters. The dredging depth is 2.34 meters, and the maximum horizontal reach is 3.255 meters. The bucket width is 0.4 meters, with a bucket capacity of 0.04 cubic meters.

Mini Excavators Kubota KH41

Technical specs - KH41 Kubota

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.525 t
Transport length
3.485 m
Transport width
0.98 m
Transport height
2.22 m
Bucket capacity
0.04 m³
Bucket width
0.4 m
Track width
230 mm
Max. Reach horizontal
3.255 m
Dredging depth
2.34 m
Engine manuf.
Kubota
Engine type
D950-BH1
Engine power
13.2 kW
Displacement
0.927 l
Revolutions at max torque
2400 rpm
No. of cylinders
3

More technical details, like: bucket capacity min., bucket capacity max., standard tyres, driver protection, tear-out force, model series, dimension lxwxh, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
No
Blade
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Kubota KH41 FAQ

When was the Kubota KH41 manufactured?

The Kubota KH41 was first produced in 1988.

How much does the Kubota KH41 mini excavator weigh?

The Kubota KH41 mini excavator weighs 1.53 tons.

What are the transport dimensions of the Kubota KH41 mini excavator?

The Kubota KH41 has a transport length of 3.49 meters, a transport width of 0.98 meters, and a transport height of 2.22 meters.

What is the track width of the Kubota KH41 mini excavator?

The Kubota KH41 mini excavator has a track width of 230 mm.

What are the excavation performance specifications of the Kubota KH41 mini excavator?

The Kubota KH41 mini excavator has a dredging depth of 2.34 meters and a maximum horizontal reach of 3.255 meters.

What are the bucket specifications of the Kubota KH41 mini excavator?

The Kubota KH41 mini excavator has a bucket capacity of 0.04 cubic meters and a bucket width of 0.4 meters.
