PC30-5 Komatsu excavator specs & dimensions (1988 - 1989)

Komatsu PC30-5 is a mini excavator manufactured from 1988 to 1989, with a weight of 3.15 tons. It features a track width of 300 mm…

Komatsu PC30-5 is a mini excavator manufactured from 1988 to 1989, with a weight of 3.15 tons. It features a track width of 300 mm, a transport length of 4.9 meters, a transport width of 1.52 meters, and a transport height of 1.325 meters. The machine has a tear-out force of 23.6 kN and a bucket capacity of 0.12 cubic meters. It is equipped with a rubber track.

Mini Excavators Komatsu PC30-5

Visit Komatsu live at

Technical specs - PC30-5 Komatsu

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.15 t
Transport length
4.9 m
Transport width
1.52 m
Transport height
1.325 m
Bucket capacity
0.12 m³
Track width
300 mm
Driver protection
KbR
Tear-out force
23.6 kN
Model series
PC
Engine manuf.
Komatsu
Engine type
3D84-1G
Engine power
22.1 kW
Displacement
1.413 l
Revolutions at max torque
2700 rpm

More technical details, like: bucket capacity min., bucket capacity max., bucket width, standard tyres, max. reach horizontal, dredging depth, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
Yes
Blade
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Komatsu PC30-5 FAQ

When was the Komatsu PC30-5 manufactured?

The Komatsu PC30-5 was manufactured from 1988 to 1989.

How much does the Komatsu PC30-5 weigh?

The Komatsu PC30-5 weighs 3.15 tons.

What are the transport dimensions of the Komatsu PC30-5 mini excavator?

The Komatsu PC30-5 has a transport length of 4.9 meters, a transport width of 1.52 meters, and a transport height of 1.33 meters.

What is the track width of the Komatsu PC30-5 mini excavator?

The Komatsu PC30-5 mini excavator has a track width of 300 mm.

Does the Komatsu PC30-5 mini excavator have any power rating data available?

The available data for the Komatsu PC30-5 mini excavator does not include power ratings; it only specifies a tear-out force of 23.6 kN, which is a force measurement, not a power rating.

What is the bucket capacity of the Komatsu PC30-5 mini excavator?

The Komatsu PC30-5 mini excavator has a bucket capacity of 0.12 cubic meters.

What operator safety and support features does the Komatsu PC30-5 have?

The Komatsu PC30-5 is equipped with a cabin that includes ROPS for driver protection.

How much is a Komatsu PC30-5 Mini excavator (1988u20131989) worth?

The residual value of the Komatsu PC30-5 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
