40 NX 2 Kato Imer excavator specs & dimensions (2008 - 2020)

Kato Imer 40 NX 2 is a mini excavator manufactured from 2008 to 2020, with a weight of 4.43 tons. It has a transport length of 5.7…

Kato Imer 40 NX 2 is a mini excavator manufactured from 2008 to 2020, with a weight of 4.43 tons. It has a transport length of 5.71 meters, a transport width of 2.45 meters, and a transport height of 1.95 meters. The excavator is equipped with a blade.

40 NX 2

Years of manufacture: 2008—2020

Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 40 NX 2 Kato Imer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.43 t

Transport length: 5.71 m

Transport width: 2.45 m

Transport height: 1.95 m

Driver protection: Kb

Max. Reach horizontal: 5.31 m

Dredging depth: 3.4 m

Model series: NX

Engine manuf.: Isuzu

Engine type: 4 LE 2

Engine power: 29.7 kW

Revolutions at max torque: 2300 rpm

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, track width, standard tyres, tear-out force, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: No
Rubber track: No
Blade: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Kato Imer 40 NX 2 FAQ

When was the Kato Imer 40 NX 2 manufactured?

The Kato Imer 40 NX 2 was manufactured from 2008 to 2020.

How much does the Kato Imer 40 NX 2 weigh?

The Kato Imer 40 NX 2 weighs 4.43 tons.

What are the transport dimensions of the Kato Imer 40 NX 2 mini excavator?

The Kato Imer 40 NX 2 has a transport length of 5.71 meters, a transport width of 2.45 meters, and a transport height of 1.95 meters.

What are the excavation specifications of the Kato Imer 40 NX 2 mini excavator?

The Kato Imer 40 NX 2 has a dredging depth of 3.4 meters and a maximum horizontal reach of 5.31 meters.

What driver protection features does the Kato Imer 40 NX 2 have?

The Kato Imer 40 NX 2 has a cabin for driver protection.

How much is a Kato Imer 40 NX 2 Mini excavator (2008u20132020) worth?

The residual value of the Kato Imer 40 NX 2 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
