R18-9 Hyundai excavator specs & dimensions (2018 - 2020)

Hyundai R18-9 is a Mini Excavator manufactured from 2018 to 2020. It has a weight of 1.86 tons and a track width of 230 mm. The tr…

Hyundai R18-9 is a Mini Excavator manufactured from 2018 to 2020. It has a weight of 1.86 tons and a track width of 230 mm. The transport dimensions are 3.84 meters in length, 0.98 meters in width, and 2.3 meters in height. The excavator features a tear-out force of 9.4 kN, a dredging depth of 2.25 meters, and a maximum horizontal reach of 3.96 meters. The bucket width is 0.44 meters with a capacity of 0.04 cubic meters. Special equipment includes a blade, rubber track, and track adjustment.

Mini Excavators Hyundai R18-9

Visit Hyundai live at

Technical specs - R18-9 Hyundai

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.86 t
Transport length
3.84 m
Transport width
0.98 m
Transport height
2.3 m
Bucket capacity
0.04 m³
Bucket capacity min.
0.04 m³
Bucket capacity max.
0.04 m³
Bucket width
0.44 m
Track width
230 mm
Driver protection
KbR
Max. Reach horizontal
3.96 m
Dredging depth
2.25 m
Tear-out force
9.4 kN
Model series
9
Engine manuf.
Mitsubishi
Engine type
L3E
Engine power
14 kW
Displacement
0.952 l
Revolutions at max torque
1800 rpm
Max. torque
54 Nm
No. of cylinders
3
Cylinder bore x stroke
76x70 mm
Emission level
IIIA

More technical details, like: standard tyres, dimension lxwxh are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
Yes
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Hyundai R18-9 FAQ

When was the Hyundai R18-9 manufactured?

The Hyundai R18-9 was manufactured from 2018 to 2020.

How much does the Hyundai R18-9 mini excavator weigh?

The Hyundai R18-9 mini excavator weighs 1.86 tons.

What are the transport dimensions of the Hyundai R18-9 mini excavator?

The Hyundai R18-9 mini excavator has a transport length of 3.84 meters, a transport width of 0.98 meters, and a transport height of 2.3 meters.

What is the track width of the Hyundai R18-9 mini excavator?

The Hyundai R18-9 mini excavator has a track width of 230 mm.

What are the dredging depth and maximum horizontal reach of the Hyundai R18-9 mini excavator?

The Hyundai R18-9 mini excavator has a dredging depth of 2.25 meters and a maximum horizontal reach of 3.96 meters.

What is the tear-out force of the Hyundai R18-9 mini excavator?

The Hyundai R18-9 mini excavator has a tear-out force of 9.4 kN.

What are the specifications of the bucket on the Hyundai R18-9 mini excavator?

The Hyundai R18-9 mini excavator has a bucket with a capacity of 0.04 cubic meters and a width of 0.44 meters.

What operator safety and support features does the Hyundai R18-9 have?

The Hyundai R18-9 is equipped with a cabin that includes ROPS (Roll-Over Protective Structure) for driver protection.

How much is a Hyundai R18-9 Mini excavator (2018u20132020) worth?

The residual value of the Hyundai R18-9 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
