R 25Z-9 Hyundai excavator specs & dimensions (2011 - 2026)

Hyundai R 25Z-9 is a mini excavator manufactured since 2011, with a weight of 2.6 tons. It features a track width of 300 mm, a tra…

Hyundai R 25Z-9 is a mini excavator manufactured since 2011, with a weight of 2.6 tons. It features a track width of 300 mm, a transport length of 4 meters, a transport width of 1 meter, and a transport height of 2 meters.

Mini Excavators Hyundai R 25Z-9

Visit Hyundai live at

Technical specs - R 25Z-9 Hyundai

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.6 t
Transport length
4 m
Transport width
1 m
Transport height
2 m
Track width
300 mm
Max. Reach horizontal
4.65 m
Dredging depth
2.5 m
Engine manuf.
Mitsubishi
Engine type
S3L2
Engine power
18.4 kW
Displacement
1.318 l
Revolutions at max torque
1800 rpm
Max. torque
78.64 Nm
No. of cylinders
3
Cylinder bore x stroke
78x92 mm
Emission level
Tier IIIA/EU Stage IIIA

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, driver protection, tear-out force, model series, dimension lxwxh are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
No
Blade
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Hyundai R 25Z-9 FAQ

When was the Hyundai R 25Z-9 manufactured?

The Hyundai R 25Z-9 was first produced in 2011.

How much does the Hyundai R 25Z-9 weigh?

The Hyundai R 25Z-9 weighs 2.6 tons.

What are the transport dimensions of the Hyundai R 25Z-9 mini excavator?

The Hyundai R 25Z-9 has transport dimensions of 4 meters in length, 1 meter in width, and 2 meters in height.

What is the track width of the Hyundai R 25Z-9 mini excavator's undercarriage?

The Hyundai R 25Z-9 mini excavator has a track width of 300 mm.

What are the excavation performance specifications of the Hyundai R 25Z-9 mini excavator?

The Hyundai R 25Z-9 mini excavator has a dredging depth of 2.5 meters and a maximum horizontal reach of 4.65 meters.

How much is a Hyundai R 25Z-9 Mini excavator (2011u20132025) worth?

The residual value of the Hyundai R 25Z-9 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
