ZX 25 Hitachi excavator specs & dimensions (2009 - 2010)

Hitachi ZX 25 is a mini excavator manufactured from 2009 to 2010. It has a weight of 2.53 tons and a track width of 250 mm. The tr…

Hitachi ZX 25 is a mini excavator manufactured from 2009 to 2010. It has a weight of 2.53 tons and a track width of 250 mm. The transport dimensions are 4.25 meters in length, 1.4 meters in width, and 2.39 meters in height. The bucket width is 0.42 meters with a capacity of 0.07 cubic meters. Special equipment includes a blade and rubber tracks.

Mini Excavators Hitachi ZX 25

Visit Hitachi live at

Technical specs - ZX 25 Hitachi

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.53 t
Transport length
4.25 m
Transport width
1.4 m
Transport height
2.39 m
Bucket capacity
0.07 m³
Bucket width
0.42 m
Track width
250 mm
Driver protection
Kb
Max. Reach horizontal
4.65 m
Dredging depth
2.74 m
Tear-out force
12.4 kN
Model series
ZAXIS
Engine manuf.
Shibaura
Engine type
S773L-C
Engine power
13.6 kW
Displacement
1.131 l
Revolutions at max torque
2400 rpm
No. of cylinders
3

More technical details, like: bucket capacity min., bucket capacity max., standard tyres, dimension lxwxh, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Hitachi ZX 25 FAQ

When was the Hitachi ZX 25 manufactured?

The Hitachi ZX 25 was manufactured from 2009 to 2010.

How much does the Hitachi ZX 25 weigh?

The Hitachi ZX 25 weighs 2.53 tons.

What are the transport dimensions of the Hitachi ZX 25 mini excavator?

The Hitachi ZX 25 has a transport length of 4.25 meters, a transport width of 1.4 meters, and a transport height of 2.39 meters.

What is the track width of the Hitachi ZX 25 mini excavator's undercarriage?

The Hitachi ZX 25 mini excavator has a track width of 250 mm.

What is the excavation performance of the Hitachi ZX 25 mini excavator?

The Hitachi ZX 25 mini excavator has a dredging depth of 2.74 meters and a maximum horizontal reach of 4.65 meters.

What is the power rating of the Hitachi ZX 25 mini excavator?

The available data does not provide a power rating for the Hitachi ZX 25 mini excavator.

What are the specifications of the primary work tool on the Hitachi ZX 25 mini excavator?

The primary work tool of the Hitachi ZX 25 mini excavator has a bucket capacity of 0.07 cubic meters and a bucket width of 0.42 meters.

What operator safety and support features does the Hitachi ZX 25 have?

The Hitachi ZX 25 provides operator safety through a protective cabin.

How much is a Hitachi ZX 25 Mini excavator (2009u20132010) worth?

The residual value of the Hitachi ZX 25 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
