H50C Hanix excavator specs & dimensions (2004 - 2005)

Hanix H50C is a mini excavator manufactured from 2004 to 2005, with a weight of 4.55 tons. It features a track width of 400 mm, a …

Hanix H50C is a mini excavator manufactured from 2004 to 2005, with a weight of 4.55 tons. It features a track width of 400 mm, a transport length of 5.65 meters, a transport width of 1.85 meters, and a transport height of 2.52 meters. The bucket capacity is 0.18 cubic meters. Special equipment includes a blade and rubber tracks.

H50C

Years of manufacture: 2004—2005

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - H50C Hanix

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.55 t

Transport length: 5.65 m

Transport width: 1.85 m

Transport height: 2.52 m

Bucket capacity: 0.18 m³

Track width: 400 mm

Driver protection: KbR

Max. Reach horizontal: 6.11 m

Dredging depth: 4.09 m

Tear-out force: 25.9 kN

Model series: H

Engine manuf.: Mitsubishi

Engine type: K 4 N

Engine power: 31.3 kW

Displacement: 2.29 l

Revolutions at max torque: 2400 rpm

More technical details, like: bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: No
Rubber track: Yes
Blade: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Hanix H50C FAQ

When was the Hanix H50C manufactured?

The Hanix H50C was manufactured from 2004 to 2005.

How much does the Hanix H50C mini excavator weigh?

The Hanix H50C mini excavator weighs 4.55 tons.

What are the transport dimensions of the Hanix H50C mini excavator?

The Hanix H50C has a transport length of 5.65 meters, a transport width of 1.85 meters, and a transport height of 2.52 meters.

What is the track width of the Hanix H50C mini excavator?

The Hanix H50C mini excavator has a track width of 400 mm.

What are the excavation specifications of the Hanix H50C mini excavator?

The Hanix H50C mini excavator has a dredging depth of 4.09 meters and a maximum horizontal reach of 6.11 meters.

What is the tear-out force of the Hanix H50C mini excavator?

The Hanix H50C mini excavator has a tear-out force of 25.9 kN.

What is the bucket capacity of the Hanix H50C mini excavator?

The Hanix H50C mini excavator has a bucket capacity of 0.18 cubic meters.

What operator safety and support features does the Hanix H50C have?

The Hanix H50C is equipped with a cabin that includes ROPS (Roll-Over Protective Structure) for driver protection.

How much is a Hanix H50C Mini excavator (2004u20132005) worth?

The residual value of the Hanix H50C depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Hanix H50C overview

Dimensions and weight

	Lifting Capacities (kg.)
								I
Load Point Height (m)	1.0 m	1.0 m	2.5 m	2.5 m	3.0 m	3.0 m	4.0 m	4.0 m	5.0 m	5.0 m	max	max	Length of Max Reach (m)
HSOC	3.5 m							552	624			409	621	4.6 m
2.5 m					763	763	537	724	339	526	322	505	5.1 m
1.5 m			1095	1635	820	1237	505	765	329	516	288	461	5.3 m
	0			946	1511	717	1124	457	714	309	496	287	464	5.2 m
	-1.5 m	1833	1833	943	1509	703	1109	446	703			370	588	4.5 m
I	-2.5 m	3215	3215	983	1554	733	1141					579	895	3.5 m
	3.5 m						567	587	587			617	617	4.5 m
	2.5 m			1032	1032	860	572	704	704	546	656	546	656	5.0 m
	1.5 m					1207	1056	778	892	534	643	496	599	5.2 m
	0			1467	1506	1112	1084	728	883	513	621	513	621	5.0 m
H56C	-1.5 m	2136	2136	1495	1878	1118	1079	723	877			650	787	4.3 m
	-2.5 m	3609	3609	1550	1634	1160						1005	1110	3.3 m
DSCH	3.5 m							1183	1521	772	1187	680	1062	5.3 m
	2.5 m			2483	3189			1127		752	1166	571	914	5.7 m
	1.5 m					1636	2606	1050	1635	717	1131	536	870	5.8 m
	0			2001	3131	1498	2447	964	1542	672	1083	551	901	5.6 m
	-1.5 m	3828	3828	2037	3425	1501	2455	950	1526			692	1116	4.9 m
	-2.5 m			2108	3509	1554	2512					1029	1631	3.9 m
U	3.5 m							1000	1900*	800	1400*	800	1400*	5.0 m
	2.5 m					1980	3200*	1200	2000*	900	1500*	800	1400	5.3 m
LO Boom	1.5 m					2080	3650*	1350	2360*	980	1830*	850	1610	5.6 m
	0					2080	3650*	1300	2360*	900	1830*	850	1750	5.6 m
City	-1.5 m					2000	3650*	1300	2360*			850	1900	4.3 m
I	-2.5 m					2100	3700*					1100	3000*	3.5 m

Specification	H50C	H56C	H75C	H75C City Boom
ENGINE
Type	Mitsubishi K4N	Mitsubishi K4N	Kubota V3300	Kubota V3300
Net power (ISO9249)/Rated Speed	31.1 KW (42.2 PS) / 2400 rpm	31.1 KW (42.2 PS) / 2400 rpm \|	43.4 KW (58.2 PS) / 2300 rpm \|	43.4 KW (58.2 PS) / 2300 rpm
No. of Cylinders/Capacity	4 / 2290cc	4 / 2290cc	4 / 3318cc	4 / 3318cc
Engine Dimensions Bore	90mm	90mm	98mm	98mm
Engine Dimensions Stroke	90mm	90mm	110mm	110mm
Electrical Voltage	12V	12V	12V	12V
HYDRAULIC SYSTEM
Pumps	2+2	2+2	2+2	2+2
Pump Flow	57.6x2L/min+50.4L/min+10.8 L/min	57.6x2L/min+50.4L/min+10.8 L/min	78.2×2L/min+46.7L/min	78.2x2L/min+46.7L/min
Pto Flow	57.6 L/min	57.6 L/min	78.2 L/min	78.2 L/min
Main Relief Pressure	220 / 175Kgf/cm2	220 / 175Kgf/cm2	260 / 240 Kgf/cm2	260 / 240 Kgf/cm2
Boom/Swing Cylinder	220 / 175Kgf/cm2	220 / 175Kgf/cm2	260 / 240 Kgf/cm2	260 / 240 Kgf/cm2
Operating Pressure - Travel Motor	220 Kgf/cm2	220 Kgf/cm2	260 Kgf/cm2	260 Kgf/cm2
Operating Pressure - Slew Motor	150 Kgf/cm2	150 Kgf/cm2	230 Kgf/cm2	230 Kgf/cm2
PERFORMANCE
Travel Speed Low/ High	2.8 / 4.6 km/h	2.6 / 4.3 km/h	3.1 / 5.2 Km/h	3.1 / 5.2 Km/h
Slew Speed	9.2 rpm	9.0 rpm	9.7 rpm	10.0 rpm
Std. Bucket Capacity (SAE) & Width	0.16m3 / 650mm	0.18m3 / 710mm	0.25m3 / 750mm	0.25m3 / 750mm
Bucket Tearout	44.1 kN	46.2 kN	53.0 KN	53.0 kN
Dipper Tearout Std / Lng	25.9 kN / 21.5 kN	25.9 kN / 21.5 kN	-/45.0 kN	-/45.0 kN
Drawbar Pulling Force	40.52 KN	47.73 kN	55.03 KN	55.03 KN
Rubber Shoes / Steel	Std/Opt	Std/Opt	Std/Opt	Std/Opt
Top / Bottom Rollers	1/4	1/4	1/5	1/5
Travelling Motor Type	Piston shoe in type	Piston shoe in type	Piston shoe in type	Piston shoe in type
Crawler Tension Type	Grease Cylinder	Grease Cylinder	Grease Cylinder	Grease Cylinder
Crawler Type	Rubber / Steel	Rubber / Steel	Rubber / Steel	Rubber / Steel
Ground Bearing Pressure	0.27 Kgf/cm2	0.32 Kgf/cm2	0.35 Kgf/cm2	0.35 Kgf/cm2
Noise Level	Lwa 97 dB	Lwa 97 dB	Lwa 100 dB	Lwa 100 dB
CAPACITIES
Engine Cooling Capacity	7.3 L	7.3 L	9.0 L	9.0 L
Engine Oil Capacity	6.8 L	6.8 L	8.0 L	8.0 L
Fuel tank Capacity	75.0 L	90.0 L	130.0 L	130.0 L
Hydraulic tank Capacity	60.0 L	70.0 L	85.0 L	85.0 L
Hydraulic System Capacity	95.0 L	95.0 L	136.0 L	136.0 L
WEIGHT
Operating weight with cab	4550 kg	5140 kg	7650 kg	7940 kg

Tables

Equipment	H50C	H56C	H75C	H75C City Boom
Double acting Hydraulic Circuit		V	V	V
Piped for Auxiliary Attachment		v	V
Boom Cylinder Protection				V
Cushioned Cylinders		V	V	V
Pilot Operated Joysticks	V			V
Engine Warning Indicators	V	V	V
Cab	V	V	V	V
Rubber / Steel Track	V		V
2 Speed Travel	V		V	V
Straight Line Travel	V			V
Short Pitched Rubber Tracks	V
Suspension Seat	V	V	V
Seat Head / Arm Rest			V
Working Light	V		V
Heater	V
Optional Equipment
Long Arm	V	V
Cab Guards	V	V
Rotary Beacon	V
