H 36 B Hanix excavator specs & dimensions (1998 - 2005)

Model rating: 9,00 / 10

Hanix H 36 B is a mini excavator manufactured from 1998 to 2005. It has a weight of 3.37 tons and a track width of 300 mm. The tra…

Hanix H 36 B is a mini excavator manufactured from 1998 to 2005. It has a weight of 3.37 tons and a track width of 300 mm. The transport dimensions are 5 meters in length, 1.6 meters in width, and 2.4 meters in height. The tear-out force is 18 kN, and the bucket capacity is 0.13 m³. Special equipment includes a blade and rubber track.

H 36 B

Years of manufacture: 1998—2005

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Reviews
Transport
News

Technical specs - H 36 B Hanix

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 3.37 t

Transport length: 5 m

Transport width: 1.6 m

Transport height: 2.4 m

Bucket capacity: 0.13 m³

Track width: 300 mm

Driver protection: KbR

Max. Reach horizontal: 5.07 m

Dredging depth: 3.41 m

Tear-out force: 18 kN

Model series: H

Engine manuf.: Isuzu

Engine type: 3 LD 1

Engine power: 21.3 kW

More technical details, like: bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: No
Rubber track: Yes
Blade: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Hanix H 36 B FAQ

When was the Hanix H 36 B manufactured?

The Hanix H 36 B was manufactured from 1998 to 2005.

How much does the Hanix H 36 B mini excavator weigh?

The Hanix H 36 B mini excavator weighs 3.37 tons.

What are the transport dimensions of the Hanix H 36 B mini excavator?

The Hanix H 36 B has a transport length of 5 meters, a transport width of 1.6 meters, and a transport height of 2.4 meters.

What is the track width of the Hanix H 36 B mini excavator?

The Hanix H 36 B mini excavator has a track width of 300 mm.

What is the excavation performance of the Hanix H 36 B mini excavator?

The Hanix H 36 B mini excavator has a dredging depth of 3.41 meters and a maximum horizontal reach of 5.07 meters.

What is the tear-out force of the Hanix H 36 B mini excavator?

The Hanix H 36 B mini excavator has a tear-out force of 18 kN.

What is the bucket capacity of the Hanix H 36 B mini excavator?

The Hanix H 36 B mini excavator has a bucket capacity of 0.13 cubic meters.

What operator safety features does the Hanix H 36 B offer?

The Hanix H 36 B provides operator safety with a cabin equipped with ROPS (Roll-Over Protective Structure).

How much is a Hanix H 36 B Mini excavator (1998u20132005) worth?

The residual value of the Hanix H 36 B depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Reviews

Model rating: 9,00 / 10

Hanix H 36 B user from

It is fast, reliable and powerful.

Hanix H 36 B user from

Very fast, powerful and reliable.

Hanix H 36 B overview

Engine / Driveline and transmission

Low Environmental Impact
Lean burn fuel-efficient Mitsubishi engine saves fuel and lowers emissions. Emissions comply with Stage III A (EU)/Interim Tier 4 (EPA) regulations. Engine shaft equipped with high quality sound damping to reduce noise pollution. Exceptional performance ratio for reduced emissions.

Dimensions and weight

Specification
Machine weight (Cab - Rubber Tracks / Cab - Steel Tracks)	kg	3490 / 3570
Dimension (length / width / height)	mm	5005 (5015) / 1580 / 2420
Dozer blade dimensions (width / height)	mm	1580 / 335
Bucket (capacity / width)	std. ISO7451"	m3 /mm	0.10 / 590
Noise Level		LwA / LpA	94/80
Engine	Model	–	MITSUBISHI S3L2
Displacement	cc	1318
Rated power	–	19.9kW / 27.0ps / 2400 rpm
Fuel tank capacity	litres	42
Working Range	Max. digging depth (Std / Long)	mm	3125 / 3425
Max. digging height (Std / Long)	mm	5005 / 5215
Max. dumping height (Std / Long)	mm	3535 / 3750
Max. vertical digging depth (Std / Long)	mm	2285 / 2560
Max. digging radius (Std / Long)	mm	5180 / 5465
Max. reach at ground (Std / Long)	mm	5065 / 5360
Min. turning radius front (Std / Long)	mm	2065 / 2125
Rear turning radius	mm	1410
Min. turning radius swing (Std / Long)	mm	1680 / 1740
Boom swing angle (L / R)	degrees	L80 / R50
Performance	Max. digging power Bucket / Arm (Std / Long)	kN	30.1 / 17.9 (30.1 / 15.7)
Travelling speed (low / high)	km/h	2.5 / 4.5
Slew speed	min-1	8.7
Hydraulic System	Pump Type	–	Piston 2 + Gear 1
Oil flow quantity	litres/min	42 / 42 / 25.2
PTO Oil flow quantity	litres/min	67.2
Main relief pressure	MPa	20.6 / 20.6 / 17.2
Hyd. tank capacity	litres	50.5

Lifting point Height (m)	Lifting point radius (3.0m)	Lifting point max radius
Over-front	Over-side	Over-front	Over-side	m
Blade Down	Blade Up	Blade Down	Blade Up
2.0	768	768	712	596	436	383	4.3
0.0	1057	735	634	601	421	368	4.2
-1.0	946	730	629	588	502	438	3.8

Other features

Improved Operator Comfort
Cab for operator comfort with heater / defroster, 12V auxiliary bushing, easy clean interior - and even a cup holder. Fully adjustable operator seat combined with joysticks for superior operating control. Short pitch rubber tracks reduce travel noise and vibration.

Safety

Functional Design
Hoses routed and protected to prevent damage. Enlarged engine covers and removable high shoulder counterweight for easy maintenance. All grease points and boom cylinders have protective shields as standard. PTO stop valves allow quick change of attachments.
