MB 35 VX Gehlmax-IHI excavator specs & dimensions (2007 - 2010)

Gehlmax-IHI MB 35 VX is a mini excavator manufactured from 2007 to 2010. It has a weight of 3.43 tons and a track width of 300 mm.…

Gehlmax-IHI MB 35 VX is a mini excavator manufactured from 2007 to 2010. It has a weight of 3.43 tons and a track width of 300 mm. The transport dimensions are 2.51 meters in length, 1.55 meters in width, and 2.47 meters in height. The bucket width is 0.6 meters, with a bucket capacity of 0.12 cubic meters.

Mini Excavators Gehlmax-IHI MB 35 VX

Technical specs - MB 35 VX Gehlmax-IHI

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.43 t
Transport length
2.51 m
Transport width
1.55 m
Transport height
2.47 m
Bucket capacity
0.12 m³
Bucket width
0.6 m
Track width
300 mm
Driver protection
Kb
Max. Reach horizontal
4.84 m
Dredging depth
3.45 m
Tear-out force
26.5 kN
Model series
VX
Engine manuf.
Yanmar
Engine type
3TNV88
Engine power
20.4 kW
Displacement
1.642 l
Revolutions at max torque
2200 rpm
Max. torque
106/1200 Nm
No. of cylinders
3
Cylinder bore x stroke
88x90 mm
Emission level
IIIA

More technical details, like: bucket capacity min., bucket capacity max., standard tyres, dimension lxwxh are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
No
Blade
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Gehlmax-IHI MB 35 VX FAQ

When was the Gehlmax-IHI MB 35 VX manufactured?

The Gehlmax-IHI MB 35 VX was manufactured from 2007 to 2010.

How much does the Gehlmax-IHI MB 35 VX weigh?

The Gehlmax-IHI MB 35 VX weighs 3.43 tons.

What are the transport dimensions of the Gehlmax-IHI MB 35 VX mini excavator?

The Gehlmax-IHI MB 35 VX has a transport length of 2.51 meters, a transport width of 1.55 meters, and a transport height of 2.47 meters.

What is the track width of the Gehlmax-IHI MB 35 VX mini excavator's undercarriage?

The Gehlmax-IHI MB 35 VX mini excavator has a track width of 300 mm.

What are the excavation specifications of the Gehlmax-IHI MB 35 VX mini excavator?

The Gehlmax-IHI MB 35 VX has a dredging depth of 3.45 meters and a maximum horizontal reach of 4.84 meters.

What is the tear-out force of the Gehlmax-IHI MB 35 VX mini excavator?

The Gehlmax-IHI MB 35 VX mini excavator has a tear-out force of 26.5 kN. No power rating data is available for this model.

What are the bucket specifications of the Gehlmax-IHI MB 35 VX mini excavator?

The Gehlmax-IHI MB 35 VX has a bucket capacity of 0.12 cubic meters and a bucket width of 0.6 meters.

What driver protection feature does the Gehlmax-IHI MB 35 VX have?

The Gehlmax-IHI MB 35 VX has a cabin for driver protection.

How much is a Gehlmax-IHI MB 35 VX Mini excavator (2007u20132010) worth?

The residual value of the Gehlmax-IHI MB 35 VX depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
