283Z Gehl excavator specs & dimensions (2008 - 2026)

Gehl 283Z is a mini excavator manufactured since 2008, with a weight of 2.6 tons. It features a track width of 300 mm, a transport…

Gehl 283Z is a mini excavator manufactured since 2008, with a weight of 2.6 tons. It features a track width of 300 mm, a transport length of 4.2 meters, a transport width of 1.5 meters, and a transport height of 2.4 meters. The machine has a tear-out force of 22.5 kN, a dredging depth of 2.7 meters, and a maximum horizontal reach of 4.6 meters. It comes equipped with a blade and rubber tracks.

Mini Excavators Gehl 283Z

Technical specs - 283Z Gehl

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.6 t
Transport length
4.2 m
Transport width
1.5 m
Transport height
2.4 m
Track width
300 mm
Driver protection
FD
Max. Reach horizontal
4.6 m
Dredging depth
2.7 m
Tear-out force
22.5 kN
Engine manuf.
Yanmar
Engine type
3TNV76
Engine power
15.2 kW
Displacement
3.6 l
No. of cylinders
3

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, model series, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Gehl 283Z FAQ

When was the Gehl 283Z manufactured?

The Gehl 283Z was first produced in 2008.

How much does the Gehl 283Z mini excavator weigh?

The Gehl 283Z mini excavator weighs 2.6 tons.

What are the transport dimensions of the Gehl 283Z mini excavator?

The Gehl 283Z has a transport length of 4.2 meters, a transport width of 1.5 meters, and a transport height of 2.4 meters.

What is the track width of the Gehl 283Z mini excavator?

The Gehl 283Z mini excavator has a track width of 300 mm.

What are the excavation performance specifications of the Gehl 283Z mini excavator?

The Gehl 283Z mini excavator has a dredging depth of 2.7 meters and a maximum horizontal reach of 4.6 meters.

What is the tear-out force of the Gehl 283Z mini excavator?

The Gehl 283Z mini excavator has a tear-out force of 22.5 kN.

What operator safety features does the Gehl 283Z have?

The Gehl 283Z has a canopy for driver protection.

How much is a Gehl 283Z Mini excavator (2008u20132025) worth?

The residual value of the Gehl 283Z depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Gehl 283Z overview

Hydraulics

Enclosed ROPS canopy, Advanced Hydraulic System featuring four hydraulic pumps, hydraulic oil cooler, servo operated joystick controls with armrests, double variable displacement pump, boom mounted work lights, adjustable seat, rubber tracks, SAE/ISO Central pattern selection, two-way auxiliary hydraulics with flat arranged clutches, dozer blade.

Tables

MakeYanmar
Model3TNV76
Type3-cylinder water-cooled diesel"
Displacement (cc)68 cid (1114)
Net Power (kW)20.4 hp (15.2)
Fuel Tank (L)9.5 gal. (36)
