ES 18 ZT Eurocomach excavator specs & dimensions (2012 - 2018)

Model rating
10,00 / 10

Eurocomach ES 18 ZT is a mini excavator manufactured from 2012 to 2018, with a weight of 1.73 tons. It features a track width of 2…

Eurocomach ES 18 ZT is a mini excavator manufactured from 2012 to 2018, with a weight of 1.73 tons. It features a track width of 230 mm, a transport length of 3.3 meters, a transport width of 0.99 meters, and a transport height of 2.357 meters. The dredging depth is 2.3 meters. Special equipment includes a blade, rubber track, and track adjustment.

Mini Excavators Eurocomach ES 18 ZT
Mini Excavators Eurocomach ES 18 ZT
Mini Excavators Eurocomach ES 18 ZT
Mini Excavators Eurocomach ES 18 ZT
Mini Excavators Eurocomach ES 18 ZT
Mini Excavators Eurocomach ES 18 ZT

Technical specs - ES 18 ZT Eurocomach

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.73 t
Transport length
3.3 m
Transport width
0.99 m
Transport height
2.357 m
Track width
230 mm
Driver protection
FD
Dredging depth
2.3 m
Model series
MME
Engine manuf.
Yanmar
Engine type
3TNV70
Engine power
11.2 kW
Displacement
0.854 l
Revolutions at max torque
2100 rpm
No. of cylinders
3

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, max. reach horizontal, tear-out force, dimension lxwxh, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
Yes
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Eurocomach ES 18 ZT FAQ

When was the Eurocomach ES 18 ZT manufactured?

The Eurocomach ES 18 ZT was manufactured from 2012 to 2018.

How much does the Eurocomach ES 18 ZT weigh?

The Eurocomach ES 18 ZT weighs 1.73 tons.

What are the transport dimensions of the Eurocomach ES 18 ZT mini excavator?

The Eurocomach ES 18 ZT has a transport length of 3.3 meters, a transport width of 0.99 meters, and a transport height of 2.36 meters.

What is the track width of the Eurocomach ES 18 ZT's undercarriage?

The Eurocomach ES 18 ZT has a track width of 230 mm.

What is the excavation dredging depth of the Eurocomach ES 18 ZT mini excavator?

The Eurocomach ES 18 ZT mini excavator has a dredging depth of 2.3 meters.

What operator safety and support features does the Eurocomach ES 18 ZT have?

The Eurocomach ES 18 ZT provides driver protection with a canopy.

How much is a Eurocomach ES 18 ZT Mini excavator (2012u20132018) worth?

The residual value of the Eurocomach ES 18 ZT depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Eurocomach ES 18 ZT overview

Dimensions and weight

Maximum widthmm990 - 1.300
Total heightmm2.357
Rear rotation radiusmm650
Digging arm length std (optional)mm1.150 (1.350)
Tracks widthmm230
Rollers number (for each side)n°3
FILLINGS
Fuel tanklt18
Hydraulic oil tanklt20
Hydraulic circuit capacitylt30
Cooling system capacitylt4
Engine oillt28"

Tables

Lifting capacity (kg) at 1.0 m height
15"225"3MAX
Frontal and lowered dozer blade660440360310250
Frontal and lifted dozer blade610410280205180
Lateral open undercarriage"610410235195160
Coolingwater
Consumptionlt/h24"
AlternatorV (A)12 (35)
