ES 14 SR 4 Eurocomach excavator specs & dimensions (2017 - 2020)

Eurocomach ES 14 SR 4 is a mini excavator manufactured from 2017 to 2020, with a weight of 1.23 tons. It features a track width of…

Eurocomach ES 14 SR 4 is a mini excavator manufactured from 2017 to 2020, with a weight of 1.23 tons. It features a track width of 180 mm, a transport length of 3.02 meters, a transport width of 0.79 meters, and a transport height of 2.3 meters. The dredging depth is 2.045 meters. Special equipment includes a blade, rubber track, and track adjustment.

ES 14 SR 4

Years of manufacture: 2017—2020

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - ES 14 SR 4 Eurocomach

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 1.23 t

Transport length: 3.02 m

Transport width: 0.79 m

Transport height: 2.3 m

Track width: 180 mm

Driver protection: Ü

Dredging depth: 2.045 m

Model series: MME

Engine manuf.: Yanmar

Engine type: D722

Engine power: 10.2 kW

Displacement: 0.719 l

Revolutions at max torque: 2300 rpm

No. of cylinders: 3

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, max. reach horizontal, tear-out force, dimension lxwxh, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: Yes
Rubber track: Yes
Blade: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Eurocomach ES 14 SR 4 FAQ

When was the Eurocomach ES 14 SR 4 manufactured?

The Eurocomach ES 14 SR 4 was manufactured from 2017 to 2020.

How much does the Eurocomach ES 14 SR 4 weigh?

The Eurocomach ES 14 SR 4 weighs 1.23 tons.

What are the transport dimensions of the Eurocomach ES 14 SR 4 mini excavator?

The Eurocomach ES 14 SR 4 has a transport length of 3.02 meters, a transport width of 0.79 meters, and a transport height of 2.3 meters.

What is the track width of the Eurocomach ES 14 SR 4's undercarriage?

The Eurocomach ES 14 SR 4 has a track width of 180 mm.

What is the dredging depth of the Eurocomach ES 14 SR 4 mini excavator?

The Eurocomach ES 14 SR 4 mini excavator has a dredging depth of 2.045 meters.

What operator safety features does the Eurocomach ES 14 SR 4 have?

The Eurocomach ES 14 SR 4 is equipped with a roll-over bar for driver protection.

How much is a Eurocomach ES 14 SR 4 Mini excavator (2017u20132020) worth?

The residual value of the Eurocomach ES 14 SR 4 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
