25 ZT Eurocomach excavator specs & dimensions (2019 - 2023)

Eurocomach 25 ZT is a mini excavator manufactured since 2019, with a weight of 2.58 tons. It features a track width of 280 mm, a t…

Eurocomach 25 ZT is a mini excavator manufactured since 2019, with a weight of 2.58 tons. It features a track width of 280 mm, a transport length of 4.51 meters, a transport width of 1.5 meters, and a transport height of 2.527 meters. The machine has a tear-out force of 22 kN, a dredging depth of 2.7 meters, and a maximum horizontal reach of 4.77 meters. Special equipment includes a blade, quick hitch hydraulic, quick hitch mechanical, and rubber tracks.

25 ZT

Years of manufacture: 2019—2023

Data sheet
Buy & Rent
Spare parts
Transport
News

Technical specs - 25 ZT Eurocomach

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.58 t

Transport length: 4.51 m

Transport width: 1.5 m

Transport height: 2.527 m

Track width: 280 mm

Driver protection: KbR

Max. Reach horizontal: 4.77 m

Dredging depth: 2.7 m

Tear-out force: 22 kN

Model series: MME

Engine manuf.: Yanmar

Engine type: 3TNV76

Engine power: 13.7 kW

Displacement: 1.116 l

Revolutions at max torque: 2200 rpm

No. of cylinders: 3

Emission level: V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: No
Rubber track: Yes
Blade: Yes
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: Yes

Download datasheets (PDF)

Eurocomach 25 ZT FAQ

When was the Eurocomach 25 ZT manufactured?

The Eurocomach 25 ZT was manufactured from 2019 to 2023.

How much does the Eurocomach 25 ZT weigh?

The Eurocomach 25 ZT weighs 2.58 tons.

What are the transport dimensions of the Eurocomach 25 ZT mini excavator?

The Eurocomach 25 ZT has a transport length of 4.51 meters, a transport width of 1.5 meters, and a transport height of 2.53 meters.

What is the track width of the Eurocomach 25 ZT mini excavator?

The Eurocomach 25 ZT mini excavator has a track width of 280 mm.

What are the excavation performance specifications of the Eurocomach 25 ZT mini excavator?

The Eurocomach 25 ZT mini excavator has a dredging depth of 2.7 meters and a maximum horizontal reach of 4.77 meters.

What is the tear-out force of the Eurocomach 25 ZT mini excavator?

The Eurocomach 25 ZT mini excavator has a tear-out force of 22 kN.

What operator safety and support features does the Eurocomach 25 ZT have?

The Eurocomach 25 ZT is equipped with a cabin that includes ROPS (Roll-Over Protective Structure) for driver protection.

How much is a Eurocomach 25 ZT Mini excavator (2019u20132023) worth?

The residual value of the Eurocomach 25 ZT depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Eurocomach 25 ZT overview

Dimensions and weight

HYDRAULIC SYSTEM
Pump type	variable flow
Pump displacement	cc	2 x 13 + 8	3"
Pump capacity	lt/min	2 x 28	5 + 18"
Max. circuit calibration pressure	bar	230
Auxiliary system: Max capacity Max pressure	lt/min bar	45 210
PERFORMANCES
Max digging depth standard arm (optional arm)	mm	2.725 (2.925)
Max dumping height with canopy standard arm (optional arm)	mm	3.354 (3.488)
Max dumping height with cab standard arm (optional arm)	mm	3.212 (3.330)
Bucket breaking force (standard arm) ISO 6015	daN	2.200
Arm breaking force (standard arm) ISO 6015	daN	1.450
Traction force	daN	2.200
Ground bearing pressure with rubber tracks and canopy (with cabin)	kg/cm2	0	28 (0	29)"
Max slope		60% - 30°
DIMENSIONS
Maximum width	mm	1.500
Total height	mm	2.527
Rear rotation radius	mm	750
Digging arm length std (optional)	mm	1.350 (1.550)
Tracks width	mm	280
Rollers number (for each side)	n°	4
FILLINGS
Fuel tank	lt	26
Hydraulic oil tank	lt	29
Hydraulic circuit capacity	lt	40
Cooling system capacity	lt	5
Engine oil	lt	2	8"
CONTROLS

Tables

	2	2	5"	3	3	5"	4	MAX
Frontal and lowered dozer blade	1048	709	557	479	422	413
Frontal and lifted dozer blade	750	548	428	330	266	248
Lateral	795	578	446	349	281	270

Boom	dipper stick	bucket and turret swing"	2 pilot joysticks
Track movements (included counter rotation)	2 pilot levers
Dozer blade	pilot lever
Auxiliary circuit (simple or double effect)	electroproportional switch on right joystick
Boom swing	electroproportional switch on left joystick
