22 SR Eurocomach excavator specs & dimensions (2019 - 2023)

Eurocomach 22 SR is a mini excavator manufactured since 2019. It has a weight of 2.19 tons and a track width of 230 mm. The transp…

Eurocomach 22 SR is a mini excavator manufactured since 2019. It has a weight of 2.19 tons and a track width of 230 mm. The transport dimensions are 4.145 meters in length, 0.99 meters in width, and 2.395 meters in height. The machine features a tear-out force of 16 kN, a dredging depth of 2.56 meters, and a maximum horizontal reach of 4.38 meters. Special equipment includes air conditioning, a blade, hydraulic and mechanical quick hitches, rubber tracks, and track adjustment.

22 SR

Years of manufacture: 2019—2023

Data sheet
Buy & Rent
Spare parts
Transport
News

Technical specs - 22 SR Eurocomach

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.19 t

Transport length: 4.145 m

Transport width: 0.99 m

Transport height: 2.395 m

Track width: 230 mm

Driver protection: KbR

Max. Reach horizontal: 4.38 m

Dredging depth: 2.56 m

Tear-out force: 16 kN

Model series: MME

Engine manuf.: Kubota

Engine type: D1105

Engine power: 15.4 kW

Displacement: 1.123 l

Revolutions at max torque: 2400 rpm

Max. torque: 70,3/1600 Nm

No. of cylinders: 3

Cylinder bore x stroke: 78x78,4 mm

Emission level: V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: Yes
Rubber track: Yes
Blade: Yes
Aircondition: Yes
Quick hitch hydr.: Yes
Quick hitch mech.: Yes

Download datasheets (PDF)

Eurocomach 22 SR FAQ

When was the Eurocomach 22 SR manufactured?

The Eurocomach 22 SR was manufactured from 2019 to 2023.

How much does the Eurocomach 22 SR weigh?

The Eurocomach 22 SR weighs 2.19 tons.

What are the transport dimensions of the Eurocomach 22 SR mini excavator?

The Eurocomach 22 SR has a transport length of 4.15 meters, a transport width of 0.99 meters, and a transport height of 2.4 meters.

What is the track width of the Eurocomach 22 SR mini excavator?

The Eurocomach 22 SR mini excavator has a track width of 230 mm.

What are the excavation performance specifications of the Eurocomach 22 SR mini excavator?

The Eurocomach 22 SR mini excavator has a dredging depth of 2.56 meters and a maximum horizontal reach of 4.38 meters.

What are the power ratings of the Eurocomach 22 SR mini excavator?

The source data does not provide power ratings for the Eurocomach 22 SR mini excavator. The only related specification available is a tear-out force of 16 kN.

What operator safety and support features does the Eurocomach 22 SR have?

The Eurocomach 22 SR is equipped with a cabin that includes ROPS for driver protection.

How much is a Eurocomach 22 SR Mini excavator (2019u20132023) worth?

The residual value of the Eurocomach 22 SR depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Eurocomach 22 SR overview

Dimensions and weight

DIMENSIONS
Maximum width	mm	990 - 1.300
Total height	mm	2.395
Rear rotation radius	mm	1.000
Digging arm length std (optional)	mm	1.250 (1.450)
Tracks width	mm	230
Rollers number (for each side)	n°	3
FILLINGS
Fuel tank	lt	20
Hydraulic oil tank	lt	16
Hydraulic circuit capacity	lt	25
Cooling system capacity	lt	4
Engine oil	lt	4	4"

Tables

	2	MAX
Frontal and lowered dozer blade	700	400
Frontal and lifted dozer blade	700	270
Lateral	open undercarriage"	700	260

CONTROLS
Boom	dipper stick	bucket and turret swing"	2 pilot joysticks
Track movements	2 pilot levers
Dozer blade	pilot lever
Auxiliary circuit (simple or double effect)	electroproportional switch on right joystick
Boom swing	electroproportional switch on left joystick
