17sa Eurocomach excavator specs & dimensions (2022 - 2023)

Menzi 17sa is a mini excavator manufactured since 2022, with a weight of 1.77 tons. It features a track width of 230 mm, a transpo…

Menzi 17sa is a mini excavator manufactured since 2022, with a weight of 1.77 tons. It features a track width of 230 mm, a transport length of 2.62 meters, a transport width of 0.99 meters, and a transport height of 2.37 meters. The machine has a tear-out force of 15 kN, a dredging depth of 2.22 meters, and a maximum horizontal reach of 3.82 meters. It is equipped with a blade and rubber tracks.

Mini Excavators Eurocomach 17sa

Technical specs - 17sa Eurocomach

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.77 t
Transport length
2.62 m
Transport width
0.99 m
Transport height
2.37 m
Track width
230 mm
Driver protection
Kb
Max. Reach horizontal
3.82 m
Dredging depth
2.22 m
Tear-out force
15 kN
Engine manuf.
Yanmar
Engine type
3TNV70
Engine power
11.3 kW
Displacement
0.854 l
Revolutions at max torque
2200 rpm
No. of cylinders
3
Emission level
V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, model series, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Eurocomach 17sa FAQ

When was the Eurocomach 17sa manufactured?

The Eurocomach 17sa was manufactured from 2022 to 2023.

How much does the Eurocomach 17sa weigh?

The Eurocomach 17sa weighs 1.77 tons.

What are the transport dimensions of the Eurocomach 17sa mini excavator?

The Eurocomach 17sa has transport dimensions of 2.62 meters in length, 0.99 meters in width, and 2.37 meters in height.

What is the track width of the Eurocomach 17sa mini excavator?

The Eurocomach 17sa mini excavator has a track width of 230 mm.

What are the excavation performance specifications of the Eurocomach 17sa mini excavator?

The Eurocomach 17sa mini excavator has a dredging depth of 2.22 meters and a maximum horizontal reach of 3.82 meters.

What is the tear-out force of the Eurocomach 17sa mini excavator?

The Eurocomach 17sa mini excavator has a tear-out force of 15 kN.

What operator safety features does the Eurocomach 17sa have?

The Eurocomach 17sa has a cabin for driver protection.

How much is a Eurocomach 17sa Mini excavator (2022u20132023) worth?

The residual value of the Eurocomach 17sa depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
