DX17Z Develon excavator specs & dimensions (2021 - 2023)

Doosan DX17Z is a mini excavator manufactured since 2021, with a weight of 1.75 tons. It features a track width of 230 mm and has …

Doosan DX17Z is a mini excavator manufactured since 2021, with a weight of 1.75 tons. It features a track width of 230 mm and has transport dimensions of 3.45 m in length, 0.98 m in width, and 2.297 m in height. The machine offers a tear-out force of 9.11 kN, a dredging depth of 2.249 m, and a maximum horizontal reach of 3.971 m. It comes equipped with a blade and rubber tracks.

Visit Develon live at

DX17Z

Years of manufacture: 2021—2023

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - DX17Z Develon

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 1.75 t

Transport length: 3.45 m

Transport width: 0.98 m

Transport height: 2.3 m

Track width: 230 mm

Max. Reach horizontal: 3.971 m

Dredging depth: 2.249 m

Tear-out force: 9.11 kN

Model series: DX

Engine manuf.: Kubota

Engine type: D722-EF11

Engine power: 9.9 kW

Displacement: 0.72 l

Revolutions at max torque: 2000 rpm

Max. torque: 42.3 Nm

No. of cylinders: 3

Cylinder bore x stroke: 67x68 mm

Emission level: V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, driver protection, dimension lxwxh are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: No
Rubber track: Yes
Blade: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Develon DX17Z FAQ

When was the Develon DX17Z manufactured?

The Develon DX17Z was manufactured from 2021 to 2023.

How much does the Develon DX17Z mini excavator weigh?

The Develon DX17Z mini excavator weighs 1.75 tons.

What are the transport dimensions of the Develon DX17Z mini excavator?

The Develon DX17Z has a transport length of 3.45 meters, a transport width of 0.98 meters, and a transport height of 2.3 meters.

What is the track width of the Develon DX17Z mini excavator?

The Develon DX17Z mini excavator has a track width of 230 mm.

What is the excavation performance of the Develon DX17Z mini excavator?

The Develon DX17Z mini excavator has a dredging depth of 2.249 meters and a maximum horizontal reach of 3.971 meters.

What is the tear-out force of the Develon DX17Z mini excavator?

The Develon DX17Z mini excavator has a tear-out force of 9.11 kN.

How much is a Develon DX17Z Mini excavator (2021u20132023) worth?

The residual value of the Develon DX17Z depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Develon DX17Z overview

Hydraulics

Versatility with powerful hydraulics
This machine makes the best possible use of engine performance. Fast cycle times, combined with smooth control of class-leading breakout forces, ensure maximum productivity. Boom and arm cylinder damping unique in their class increase overall smoothness of the working circuit. The DX17Z includes the architecture of the 2-ton class hydraulic system featuring a combination of variable piston pumps and gear pump. With optimized stability and lifting force, the DX17Z offers you the highest versatility when operating various attachments.

Tyres / Tracks

Zero House Swing
The Zero House Swing (ZHS) concept is a step above the Zero Tail Swing (ZTS) functionality as it fully protects the front upper structure corners within the oscillating circuit. ZHS functionality provides 320 free rotation, working close to any object. With our DX17Z you get ZHS without sacrificing operator comfort or performance.
Maximum stability
Stability is vital for the maximum use of digging forces and lifting capacities. Optimum stability is achieved by fully extending the retractable undercarriage and using the long dozer blade. The following features make the Doosan DX17Z very competitive with all other zero tail swing machines on the market: Retractable Undercarriage: When completely retracted, the undercarriage allows the excavator to go through tight spaces; and fully extended provides optimum footing reliability for the excavator, especially when working over the side. Expansion and retraction are simple and easy via an electric switch at the control panel. Long dozer shovel: Thanks to its dust pan functionality, also the (optional) long dozer disc significantly improves front stability, allowing the operator to take full advantage of breakout forces supplied by the machine.

Dimensions and weight

Lift point height (mm)	Maximum radius (mm)	Lift at max. radius (kg)	Lift at 2000 mm radius (kg)	Lift at 3000 mm radius (kg)
2000	3000	233	-	-
1000	3380	190	425	229
Ground	3350	182	380	214
-1000	2940	215	363	-

Lift point height (mm)	Maximum radius (mm)	Lift at max. radius (kg)	Lift at 2000 mm radius (kg)	Lift at 3000 mm radius (kg)
2000	3000	263	-	-
1000	3380	218	438*	264
Ground	3350	210	431	251
-1000	2940	249	425	-


Operating weight with ROPS canopy (ISO 6016)	1749 kg
Transport weight (bucket and operator excluded)	1632 kg
Ground pressure with rubber tracks	30.06 kPa (4360 psi)

Lift point height (mm)	Maximum radius (mm)	Lift at max. radius (kg)	Lift at 2000 mm radius (kg)	Lift at 3000 mm radius (kg)
2000	3000	344*	-	-
1000	3380	337*	438*	369*
Ground	3350	320*	742*	398*
-1000	2940	306*	609*	-


A	Blade height	235 mm
B	Ground clearance	419 mm
C	Engine cover height	1138 mm
D	Length of track on ground	1114 mm
E	Machine centre line to blade	std / long dozer blade"	1045 / 1252 mm
F	Min. radius in travel position	2715 mm
G	Overall track length	1476 mm
H	Shipping length	3450 mm
I	Track lug height	25 mm
J	Blade width (retracted)	1360 (980) mm
K	Overall height	2297 mm
L	Track width	230 mm
M	LH boom offset	450 mm
N	RH boom offset	638 mm
O	Min. turning radius	1190 mm
P	Swing clearance	rear"	690 mm
Q	Working width at max. RH rotation	1532 mm
R	Working width at max. LH rotation	1370 mm

Other features

Easy access for maintenance
From the very beginning, we've been paying particular attention to easy service access: these units feature a single point of access for daily servicing of all major components, checking fuel gauge and refueling through lockable cap.

Tables

Pump type	Dual outlet variable displacement piston pump with gear pumps
Pump capacity	2 × 15 l/min
Gear pump capacity	11.3 l/min
Auxiliary flow	30 l/min
Auxiliary relief	180 bar


Model	Kubota / D722-EF11 (EU Stage V)
No. of cylinders	3
Piston displacement	0.72 l
Max. net power @ 2500 RPM (ISO 9249)	9.9 kW (13.3 hp)
Max. net torque @ 2000 RPM (SAE J1349)	4.0 kgf/m (42.3 Nm)
Bore × stroke	67 mm × 68 mm


Bucket digging force (ISO 6015)	16177 N
Arm digging force (ISO 6015)	9108 N
Drawbar pull	19302 N
Travel speed fast / slow	4.0 / 2.48 km/h
Gradeability	30°


Swing speed	10.1 RPM
Boom swing angle L/R	80° / 60°
Swing drive	Orbit motor


Fuel tank	19 l
Hydraulic system	14.3 l
Cooling system	19.0 l
Engine oil plus oil filter	3.3 l

A-weighted emission sound pressure level at the operator’s position	LpAd (2000/14/EC)"	80 dB(A)
A-weighted sound power level	LwAd (2000/14/EC)"	93 dB(A)
Whole body vibration (ISO 2631–1)	0.14 ms-2
Hand-arm vibration (ISO 5349–1)	0.49 ms-2

Battery switch off
Spark arrester muffler
Boom light metal protection
Storage compartment
Cup holders
Demolition Kit consists of an hydraulic oil cooler for breaker application
Long dozer blade
