304E 2 CR Caterpillar excavator specs & dimensions (2020 - 2021)

Caterpillar 304E 2 CR is a Mini Excavator manufactured from 2020 to 2021. It has a weight of 4.05 tons and a track width of 350 mm…

Caterpillar 304E 2 CR is a Mini Excavator manufactured from 2020 to 2021. It has a weight of 4.05 tons and a track width of 350 mm. The transport dimensions are 4.82 meters in length, 1.95 meters in width, and 2.5 meters in height. The machine features a tear-out force of 37.8 kN, a dredging depth of 3.13 meters, and a maximum horizontal reach of 5.22 meters. The bucket capacity is 0.054 cubic meters. Special equipment includes a blade and rubber tracks.

Mini Excavators Caterpillar 304E 2 CR

Technical specs - 304E 2 CR Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
4.05 t
Transport length
4.82 m
Transport width
1.95 m
Transport height
2.5 m
Bucket capacity
0.054 m³
Track width
350 mm
Driver protection
KbR
Max. Reach horizontal
5.22 m
Dredging depth
3.13 m
Tear-out force
37.8 kN
Model series
CR
Engine manuf.
Caterpillar
Engine type
C2.4
Engine power
31 kW
Displacement
2.4 l
No. of cylinders
4
Cylinder bore x stroke
87x102.4 mm
Emission level
EPA Tier 4 f/ Stage V

More technical details, like: bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, revolutions at max torque, max. torque are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download specalog and datasheets (PDF)

Caterpillar 304E 2 CR FAQ

When was the Caterpillar 304E 2 CR manufactured?

The Caterpillar 304E 2 CR was manufactured from 2020 to 2021.

How much does the Caterpillar 304E 2 CR weigh?

The Caterpillar 304E 2 CR weighs 4.05 tons.

What are the transport dimensions of the Caterpillar 304E 2 CR mini excavator?

The Caterpillar 304E 2 CR has a transport length of 4.82 meters, a transport width of 1.95 meters, and a transport height of 2.5 meters.

What is the track width of the Caterpillar 304E 2 CR's undercarriage?

The Caterpillar 304E 2 CR has a track width of 350 mm on its undercarriage.

What are the excavation performance specifications of the Caterpillar 304E 2 CR mini excavator?

The Caterpillar 304E 2 CR mini excavator has a dredging depth of 3.13 meters and a maximum horizontal reach of 5.22 meters.

What is the tear-out force of the Caterpillar 304E 2 CR mini excavator?

The Caterpillar 304E 2 CR mini excavator has a tear-out force of 37.8 kN.

What is the bucket capacity of the Caterpillar 304E 2 CR mini excavator?

The bucket capacity of the Caterpillar 304E 2 CR mini excavator is 0.054 cubic meters.

What operator safety and support features does the Caterpillar 304E 2 CR have?

The Caterpillar 304E 2 CR is equipped with a cabin that includes ROPS (Roll-Over Protective Structure) for driver protection.
