CX17B Case excavator specs & dimensions (2010 - 2025)

Case CX17B is a mini excavator manufactured since 2010. It has a weight of 1.65 tons and a track width of 230 mm. The transport di…

Case CX17B is a mini excavator manufactured since 2010. It has a weight of 1.65 tons and a track width of 230 mm. The transport dimensions are 3.42 meters in length, 1.32 meters in width, and 2.35 meters in height. The machine features a tear-out force of 15.2 kN, a dredging depth of 2.37 meters, and a maximum horizontal reach of 4.12 meters. The bucket width is 0.41 meters, with a bucket capacity ranging from 0.024 to 0.036 cubic meters.

Mini Excavators Case CX17B

Technical specs - CX17B Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.65 t
Transport length
3.42 m
Transport width
1.32 m
Transport height
2.35 m
Bucket capacity min.
0.024 m³
Bucket capacity max.
0.036 m³
Bucket width
0.41 m
Track width
230 mm
Max. Reach horizontal
4.12 m
Dredging depth
2.37 m
Tear-out force
15.2 kN
Model series
B
Engine manuf.
Mitsubishi
Engine type
L3E-W231KBS
Engine power
11.3 kW
Displacement
0.95 l
Revolutions at max torque
1800 rpm
Max. torque
53.5 Nm
No. of cylinders
3
Cylinder bore x stroke
76x70 mm
Emission level
Tier IV

More technical details, like: bucket capacity, standard tyres, driver protection, dimension lxwxh are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
No
Blade
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Case CX17B FAQ

When was the Case CX17B manufactured?

The Case CX17B was first produced in 2010.

How much does the Case CX17B mini excavator weigh?

The Case CX17B mini excavator weighs 1.65 tons.

What are the transport dimensions of the Case CX17B mini excavator?

The Case CX17B has a transport length of 3.42 meters, a transport width of 1.32 meters, and a transport height of 2.35 meters.

What is the track width of the Case CX17B mini excavator's undercarriage?

The Case CX17B mini excavator has a track width of 230 mm.

What are the excavation performance specifications of the Case CX17B mini excavator?

The Case CX17B mini excavator has a dredging depth of 2.37 meters and a maximum horizontal reach of 4.12 meters.

What is the tear-out force of the Case CX17B mini excavator?

The Case CX17B mini excavator has a tear-out force of 15.2 kN.

What are the bucket specifications of the Case CX17B mini excavator?

The Case CX17B mini excavator has a bucket width of 0.41 meters, with a bucket capacity ranging from 0.02 to 0.04 cubic meters.
