E45 Bobcat excavator specs & dimensions (2010 - 2021)

Bobcat E45 is a mini excavator manufactured from 2010 to 2021, with a weight of 4.63 tons. It features a track width of 400 mm, a …

Bobcat E45 is a mini excavator manufactured from 2010 to 2021, with a weight of 4.63 tons. It features a track width of 400 mm, a transport length of 5.35 meters, a transport width of 1.96 meters, and a transport height of 2.53 meters. The dredging depth is 3.3 meters, and the maximum horizontal reach is 5.67 meters.

Visit Bobcat live at

E45

Years of manufacture: 2010—2021

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - E45 Bobcat

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.63 t

Transport length: 5.35 m

Transport width: 1.96 m

Transport height: 2.53 m

Track width: 400 mm

Driver protection: Kb

Max. Reach horizontal: 5.67 m

Dredging depth: 3.3 m

Model series: E

Engine manuf.: Kubota

Engine type: V2403-M-DI-E3B-BC-5

Engine power: 30.2 kW

Displacement: 2.433 l

Revolutions at max torque: 1400 rpm

Max. torque: 152.7 Nm

No. of cylinders: 4

Emission level: TIER4

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, tear-out force, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: No
Rubber track: No
Blade: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Bobcat E45 FAQ

When was the Bobcat E45 manufactured?

The Bobcat E45 was manufactured from 2010 to 2021.

How much does the Bobcat E45 weigh?

The Bobcat E45 weighs 4.63 tons.

What are the transport dimensions of the Bobcat E45 mini excavator?

The Bobcat E45 has a transport length of 5.35 meters, a transport width of 1.96 meters, and a transport height of 2.53 meters.

What is the track width of the Bobcat E45 mini excavator?

The Bobcat E45 mini excavator has a track width of 400 mm.

What are the excavation performance specifications of the Bobcat E45 mini excavator?

The Bobcat E45 mini excavator has a dredging depth of 3.3 meters and a maximum horizontal reach of 5.67 meters.

What operator safety features does the Bobcat E45 have?

The Bobcat E45 has a cabin for driver protection.

How much is a Bobcat E45 Mini excavator (2010u20132021) worth?

The residual value of the Bobcat E45 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
