E34 Bobcat excavator specs & dimensions (2019 - 2026)

Bobcat E34 is a mini excavator manufactured since 2019. It has a weight of 3.48 tons and a track width of 300 mm. The transport di…

Bobcat E34 is a mini excavator manufactured since 2019. It has a weight of 3.48 tons and a track width of 300 mm. The transport dimensions are 4.66 meters in length, 1.55 meters in width, and 2.47 meters in height. The machine features a tear-out force of 33.43 kN, a dredging depth of 3.12 meters, and a maximum horizontal reach of 5.1 meters. It is equipped with a blade as special equipment.

Mini Excavators Bobcat E34

Visit Bobcat live at

Technical specs - E34 Bobcat

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.48 t
Transport length
4.66 m
Transport width
1.55 m
Transport height
2.47 m
Track width
300 mm
Max. Reach horizontal
5.1 m
Dredging depth
3.12 m
Tear-out force
33.43 kN
Model series
R
Engine manuf.
Kubota
Engine type
D1703-M-D1-E4B-BC-2
Engine power
18.2 kW
Displacement
1.64 l
Revolutions at max torque
2200 rpm
Max. torque
97.4 Nm
No. of cylinders
3
Emission level
V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, driver protection, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
No
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Bobcat E34 FAQ

When was the Bobcat E34 manufactured?

The Bobcat E34 was first produced in 2019.

How much does the Bobcat E34 weigh?

The Bobcat E34 weighs 3.48 tons.

What are the transport dimensions of the Bobcat E34 mini excavator?

The Bobcat E34 has a transport length of 4.66 meters, a transport width of 1.55 meters, and a transport height of 2.47 meters.

What is the track width of the Bobcat E34 mini excavator?

The Bobcat E34 mini excavator has a track width of 300 mm.

What is the excavation performance of the Bobcat E34 mini excavator?

The Bobcat E34 mini excavator has a dredging depth of 3.12 meters and a maximum horizontal reach of 5.1 meters.

What is the tear-out force of the Bobcat E34 mini excavator?

The Bobcat E34 mini excavator has a tear-out force of 33.43 kN.

How much is a Bobcat E34 Mini excavator (2019u20132025) worth?

The residual value of the Bobcat E34 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
