E26 Bobcat excavator specs & dimensions (2020 - 2026)

Bobcat E26 is a mini excavator manufactured since 2020, with a weight of 2.56 tons. It features a track width of 300 mm, a transpo…

Bobcat E26 is a mini excavator manufactured since 2020, with a weight of 2.56 tons. It features a track width of 300 mm, a transport length of 4.33 meters, a transport width of 1.51 meters, and a transport height of 2.41 meters. The machine has a tear-out force of 15.8 kN, a dredging depth of 2.58 meters, and a maximum horizontal reach of 4.68 meters. It is equipped with a blade.

Visit Bobcat live at

E26

Years of manufacture: 2020—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - E26 Bobcat

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.56 t

Transport length: 4.33 m

Transport width: 1.51 m

Transport height: 2.41 m

Track width: 300 mm

Driver protection: Kb

Max. Reach horizontal: 4.68 m

Dredging depth: 2.58 m

Tear-out force: 15.8 kN

Engine manuf.: Kubota

Engine type: D1105-E4B-BCZ-1

Engine power: 15.4 kW

Displacement: 1.123 l

Revolutions at max torque: 2400 rpm

Max. torque: 71.2 Nm

No. of cylinders: 3

Emission level: V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, model series, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: No
Rubber track: No
Blade: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Bobcat E26 FAQ

When was the Bobcat E26 manufactured?

The Bobcat E26 was first produced in 2020.

How much does the Bobcat E26 weigh?

The Bobcat E26 weighs 2.56 tons.

What are the transport dimensions of the Bobcat E26 mini excavator?

The Bobcat E26 has a transport length of 4.33 meters, a transport width of 1.51 meters, and a transport height of 2.41 meters.

What is the track width of the Bobcat E26 mini excavator?

The Bobcat E26 mini excavator has a track width of 300 mm.

What are the excavation performance specifications of the Bobcat E26 mini excavator?

The Bobcat E26 mini excavator has a dredging depth of 2.58 meters and a maximum horizontal reach of 4.68 meters.

What is the tear-out force of the Bobcat E26 mini excavator?

The Bobcat E26 mini excavator has a tear-out force of 15.8 kN.

What operator safety features does the Bobcat E26 have?

The Bobcat E26 has a cabin for driver protection.

How much is a Bobcat E26 Mini excavator (2020u20132025) worth?

The residual value of the Bobcat E26 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
