    Technical specs - E19 Bobcat

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    Weight 1.768 t
    Transport length 3.83 m
    Transport width 0.98 m
    Transport height 2.299 m
    Track width 230 mm
    Driver protection Kb
    Max. Reach horizontal 4.08 m
    Dredging depth 2.39 m
    Tear-out force 10.37 kN
    Engine manuf. Kubota
    Engine type D722-E4B
    Engine power 10.2 kW
    Displacement 0.72 l
    Revolutions at max torque 2500 rpm
    Max. torque 43.5 Nm
    No. of cylinders 3
    Emission level V
    Bucket capacity ###
    Bucket capacity min. ###
    Bucket capacity max. ###
    Bucket width ###
    Standard tyres ###
    Engine power ###
    Dimension lxwxh ###
    Cylinder bore x stroke ###
    Weight ###

    Basic model with standard bucket

    E19 Bobcat - Special equipment

    • Track adaption
    • Rubber track
    • Blade
    • Aircondition
    • Quick hitch hydr.
    • Quick hitch mech.
