E17z Bobcat excavator specs & dimensions (2017 - 2021)

Bobcat E17z is a mini excavator manufactured from 2017 to 2021, with a weight of 1.75 tons. It features a track width of 230 mm, a…

Bobcat E17z is a mini excavator manufactured from 2017 to 2021, with a weight of 1.75 tons. It features a track width of 230 mm, a transport length of 3.45 meters, a transport width of 0.98 meters, and a transport height of 2.3 meters. The machine has a tear-out force of 9.11 kN, a dredging depth of 2.25 meters, and a maximum horizontal reach of 3.92 meters.

Mini Excavators Bobcat E17z
Mini Excavators Bobcat E17z
Mini Excavators Bobcat E17z
Mini Excavators Bobcat E17z
Mini Excavators Bobcat E17z
Mini Excavators Bobcat E17z

Visit Bobcat live at

Technical specs - E17z Bobcat

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.75 t
Transport length
3.45 m
Transport width
0.98 m
Transport height
2.3 m
Track width
230 mm
Driver protection
FD
Max. Reach horizontal
3.92 m
Dredging depth
2.25 m
Tear-out force
9.11 kN
Model series
E
Engine manuf.
Kubota
Engine type
D722-E2B-BCZ-7
Engine power
9.9 kW
Displacement
0.72 l
Max. torque
42.3 Nm
No. of cylinders
3
Emission level
TIER2

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
No
Blade
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Bobcat E17z FAQ

When was the Bobcat E17z manufactured?

The Bobcat E17z was manufactured from 2017 to 2021.

How much does the Bobcat E17z weigh?

The Bobcat E17z weighs 1.75 tons.

What are the transport dimensions of the Bobcat E17z mini excavator?

The Bobcat E17z has a transport length of 3.45 meters, a transport width of 0.98 meters, and a transport height of 2.3 meters.

What is the track width of the Bobcat E17z mini excavator?

The Bobcat E17z mini excavator has a track width of 230 mm.

What are the excavation performance specifications of the Bobcat E17z mini excavator?

The Bobcat E17z mini excavator has a dredging depth of 2.25 meters and a maximum horizontal reach of 3.92 meters.

What is the tear-out force of the Bobcat E17z mini excavator?

The Bobcat E17z mini excavator has a tear-out force of 9.11 kN.

What operator safety features does the Bobcat E17z have?

The Bobcat E17z has a canopy for driver protection.

How much is a Bobcat E17z Mini excavator (2017u20132021) worth?

The residual value of the Bobcat E17z depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
