E08 Bobcat excavator specs & dimensions (2008 - 2017)

Bobcat E08 is a mini excavator manufactured from 2008 to 2017, with a weight of 1.14 tons. It features a track width of 180 mm and…

Bobcat E08 is a mini excavator manufactured from 2008 to 2017, with a weight of 1.14 tons. It features a track width of 180 mm and has transport dimensions of 2.79 meters in length, 1 meter in width, and 2.21 meters in height. The machine offers a tear-out force of 8.29 kN, a dredging depth of 1.82 meters, and a maximum horizontal reach of 3.09 meters. Special equipment includes a blade, rubber track, and track adjustment.

Mini Excavators Bobcat E08
Mini Excavators Bobcat E08
Mini Excavators Bobcat E08
Mini Excavators Bobcat E08
Mini Excavators Bobcat E08
Mini Excavators Bobcat E08
Mini Excavators Bobcat E08
Mini Excavators Bobcat E08
Mini Excavators Bobcat E08
Mini Excavators Bobcat E08

Visit Bobcat live at

Technical specs - E08 Bobcat

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.14 t
Transport length
2.79 m
Transport width
1 m
Transport height
2.21 m
Track width
180 mm
Driver protection
Ü
Max. Reach horizontal
3.09 m
Dredging depth
1.82 m
Tear-out force
8.29 kN
Model series
E
Engine manuf.
Kubota
Engine type
D722-E2B-BCZ-6
Engine power
7.4 kW
Displacement
0.72 l
Revolutions at max torque
1600 rpm
Max. torque
39.1 Nm
No. of cylinders
3
Emission level
TIER2

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
Yes
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Bobcat E08 FAQ

When was the Bobcat E08 manufactured?

The Bobcat E08 was manufactured from 2008 to 2017.

How much does the Bobcat E08 weigh?

The Bobcat E08 weighs 1.14 tons.

What are the transport dimensions of the Bobcat E08 mini excavator?

The Bobcat E08 has a transport length of 2.79 meters, a transport width of 1 meter, and a transport height of 2.21 meters.

What is the track width of the Bobcat E08 mini excavator?

The Bobcat E08 mini excavator has a track width of 180 mm.

What are the excavation performance specifications of the Bobcat E08 mini excavator?

The Bobcat E08 mini excavator has a dredging depth of 1.82 meters and a maximum horizontal reach of 3.09 meters.

What is the tear-out force of the Bobcat E08 mini excavator?

The Bobcat E08 mini excavator has a tear-out force of 8.29 kN. No power ratings are provided in the available data.

What operator safety and support features does the Bobcat E08 have?

The Bobcat E08 is equipped with a roll-over bar for driver protection.

How much is a Bobcat E08 Mini excavator (2008u20132017) worth?

The residual value of the Bobcat E08 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
