E 16 Bobcat excavator specs & dimensions (2010 - 2014)

Model rating: 5,67 / 10

Bobcat E 16 is a mini excavator manufactured from 2010 to 2014, with a weight of 1.64 tons. It has a transport length of 3.93 mete…

Bobcat E 16 is a mini excavator manufactured from 2010 to 2014, with a weight of 1.64 tons. It has a transport length of 3.93 meters, a transport width of 0.98 meters, and a transport height of 2.17 meters.

Visit Bobcat live at

E 16

Years of manufacture: 2010—2014

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - E 16 Bobcat

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 1.64 t

Transport length: 3.93 m

Transport width: 0.98 m

Transport height: 2.17 m

Track width: 230 mm

Driver protection: Kb

Max. Reach horizontal: 4.15 m

Dredging depth: 2.42 m

Tear-out force: 16.64 kN

Model series: E

Engine manuf.: Kubota

Engine type: D722E

Engine power: 9.9 kW

Displacement: 0.72 l

Revolutions at max torque: 2000 rpm

Emission level: II B

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: No
Rubber track: No
Blade: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Bobcat E 16 FAQ

When was the Bobcat E 16 manufactured?

The Bobcat E 16 was manufactured from 2010 to 2014.

How much does the Bobcat E 16 mini excavator weigh?

The Bobcat E 16 mini excavator weighs 1.64 tons.

What are the transport dimensions of the Bobcat E 16 mini excavator?

The Bobcat E 16 has a transport length of 3.93 meters, a transport width of 0.98 meters, and a transport height of 2.17 meters.

What is the track width of the Bobcat E 16 mini excavator?

The Bobcat E 16 mini excavator has a track width of 230 mm.

What are the excavation performance specifications of the Bobcat E 16 mini excavator?

The Bobcat E 16 mini excavator has a dredging depth of 2.42 meters and a maximum horizontal reach of 4.15 meters.

What is the tear-out force of the Bobcat E 16 mini excavator?

The Bobcat E 16 mini excavator has a tear-out force of 16.64 kN.

What operator safety and support features does the Bobcat E 16 have?

The Bobcat E 16 has a cabin for driver protection.

How much is a Bobcat E 16 Mini excavator (2010u20132014) worth?

The residual value of the Bobcat E 16 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
