EC300ENL Volvo excavator specs & Dimensions (2019 - 2023)

Volvo EC300ENL is a crawler excavator manufactured since 2019, with a weight of 29.62 tons. It has a transport length of 10.61 met…

Volvo EC300ENL is a crawler excavator manufactured since 2019, with a weight of 29.62 tons. It has a transport length of 10.61 meters, a transport width of 2.99 meters, and a transport height of 3.51 meters. The machine offers a tear-out force of 188 kN, a dredging depth of 6.84 meters, and a maximum horizontal reach of 10.18 meters. The bucket capacity is 1.209 cubic meters. Special equipment includes air conditioning and a blade.

Crawler Excavators Volvo EC300ENL
Crawler Excavators Volvo EC300ENL
Crawler Excavators Volvo EC300ENL
Crawler Excavators Volvo EC300ENL
Crawler Excavators Volvo EC300ENL
Crawler Excavators Volvo EC300ENL
Crawler Excavators Volvo EC300ENL
Crawler Excavators Volvo EC300ENL
Crawler Excavators Volvo EC300ENL
Crawler Excavators Volvo EC300ENL
Crawler Excavators Volvo EC300ENL
Crawler Excavators Volvo EC300ENL
Crawler Excavators Volvo EC300ENL
Crawler Excavators Volvo EC300ENL

Visit Volvo live at

Technical specs - EC300ENL Volvo

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
29.62 t
Transport length
10.61 m
Transport width
2.99 m
Transport height
3.51 m
Bucket capacity
1.209 m³
Boom
MB
Max. Reach horizontal
10.18 m
Dredging depth
6.84 m
Tear-out force
188 kN
Model series
EC
Engine manuf.
Volvo
Engine type
D8J
Engine power
179 kW
Displacement
7.8 l
Revolutions at max torque
1800 rpm
Max. torque
1238/1350 Nm
No. of cylinders
6
Cylinder bore x stroke
110x136 mm
Emission level
V

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, track width, bucket width, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Volvo EC300ENL FAQ

When was the Volvo EC300ENL manufactured?

The Volvo EC300ENL was manufactured from 2019 to 2023.

How much does the Volvo EC300ENL weigh?

The Volvo EC300ENL weighs 29.62 tons.

What are the transport dimensions of the Volvo EC300ENL?

The Volvo EC300ENL has a transport length of 10.61 meters, a transport width of 2.99 meters, and a transport height of 3.51 meters.

What is the fuel consumption range of the Volvo EC300ENL crawler excavator?

The Volvo EC300ENL crawler excavator has a fuel consumption range of 13 to 25 liters per hour.

What are the excavation performance specifications of the Volvo EC300ENL?

The Volvo EC300ENL has a dredging depth of 6.84 meters, a maximum horizontal reach of 10.18 meters, and features a monobloc boom.

What is the power rating of the Volvo EC300ENL?

Power rating data is not available for the Volvo EC300ENL in the provided information.

What is the bucket capacity of the Volvo EC300ENL excavator?

The Volvo EC300ENL excavator has a bucket capacity of 1.209 cubic meters.

How much is a Volvo EC300ENL Crawler excavator (2019u20132023) worth?

The residual value of the Volvo EC300ENL depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
