EC460 Volvo excavator specs & Dimensions (2000 - 2001)

Volvo EC460 is a Crawler Excavator manufactured from 2000 to 2001, with a weight of 46 tons. It features a track width of 600 mm, …

Volvo EC460 is a Crawler Excavator manufactured from 2000 to 2001, with a weight of 46 tons. It features a track width of 600 mm, a transport length of 12.09 meters, a transport width of 3.62 meters, and a transport height of 4.79 meters. The machine has a tear-out force of 248.7 kN, a dredging depth of 9.19 meters, and a maximum horizontal reach of 13.18 meters. The bucket capacity is 3.85 cubic meters.

Crawler Excavators Volvo EC460

Visit Volvo live at

Technical specs - EC460 Volvo

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
46 t
Transport length
12.09 m
Transport width
3.62 m
Transport height
4.79 m
Bucket capacity
3.85 m³
Track width
600 mm
Max. Reach horizontal
13.18 m
Dredging depth
9.19 m
Tear-out force
248.7 kN
Engine manuf.
Cummins
Engine type
M11-C
Engine power
239 kW
Displacement
10.8 l
Revolutions at max torque
2000 rpm
Max. torque
1177/1500 Nm
No. of cylinders
6
Cylinder bore x stroke
125x147 mm

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, boom, bucket width, model series, dimension lxwxh, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Volvo EC460 FAQ

When was the Volvo EC460 manufactured?

The Volvo EC460 was manufactured from 2000 to 2001.

How much does the Volvo EC460 weigh?

The Volvo EC460 weighs 46 tons.

What are the transport dimensions of the Volvo EC460 crawler excavator?

The Volvo EC460 has a transport length of 12.09 meters, a transport width of 3.62 meters, and a transport height of 4.79 meters.

What is the track width of the Volvo EC460's undercarriage?

The Volvo EC460 has a track width of 600 mm in its undercarriage.

What are the excavation performance specifications of the Volvo EC460?

The Volvo EC460 has a dredging depth of 9.19 meters and a maximum horizontal reach of 13.18 meters.

What is the tear-out force of the Volvo EC460?

The Volvo EC460 has a tear-out force of 248.7 kN.

What is the bucket capacity of the Volvo EC460?

The Volvo EC460 has a bucket capacity of 3.85 cubic meters.

How much is a Volvo EC460 Crawler excavator (2000u20132001) worth?

The residual value of the Volvo EC460 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Volvo EC460 overview

Engine

Engine

The engine is a low-emission, turbocharged, 4-stroke diesel engine with water cooling, direct injection and aftercooler, especially developed for excavator use. The machine can work at any job site, contributing to good fuel economy, low sound level, less wear and a longer life. Air filter: 3-stage, includes pre-cleaner. Automatic idling system: Reduces the engine speed to an idling speed when levers and pedals are not activated.


Hydraulic and electronic system

Swing system

The superstructure is swung by the means of two axial piston motors and planetary reduction units. Automatic swing holding brakes and anti-rebound valves are standard.


Hydraulic system

The hydraulic system, named “Automatic Sensing Work Mode,” is designed for high productivity, high digging capacity, high maneuvering precision and good fuel economy. The summation system, boom priority, arm priority, swing priority, and regeneration system of the arm flow are provided for the best operation. The following important functions are included in the system: Summation system: Providing full use of the pump oil flow. Boom priority: Providing priority to the boom operation for fast raising during loading or deep excavation. Arm priority: Providing priority to the arm operation for faster cycle times during leveling and for increased bucket filling factors while digging. Swing priority: Providing priority to the swing operation for faster swing during simultaneous operations. Regeneration system: Enhancing the cylinder life cycle, preventing cavitation and providing priority to other movements during simultaneous operations. Power boost: All digging and lifting forces are increased. Holding valves: Boom and arm holding valves are standard. Power Max: All function speeds are increased.


Upper Structure

Drive

Each track is powered by an automatic two-speed travel motor. The track brakes are multi-disc, spring-applied and hydraulic-released. The travel motors, brake and planetary gears are well-protected in the track frame.


Cab

Cab

Easily accessible cab with a wide door and lined with sound-absorbing material. The cab, which is supported by hydraulic dampening mounts to reduce shock and vibration, has all-around visibility. The front windshield can slide up into the ceiling, and the lower front glass can be removed. Integrated air-conditioning and heating system: The pressurized and filtered cab air is supplied by a 4-speed fan. The air is distributed via 8 vents. Ergonomic operator’s seat: The adjustable seat and control consoles move independently to accommodate the operator well. The seat has eight different adjustments and a seat belt to meet any operator’s requirement. Sound level (Preliminary): According to the Directive 86/662/EEC. Exterior noise (ISO 6395) mean value of LWA (sound power level) 106 dB(A) Operator’s position (ISO 6396) with the door closed mean value of LPA (sound pressure level) 75 dB(A)
