EC230B Volvo excavator specs & Dimensions (1998 - 1999)

Volvo EC230B is a crawler excavator manufactured from 1998 to 1999. It has a weight of 24.6 tons and a track width of 600 mm. The …

Volvo EC230B is a crawler excavator manufactured from 1998 to 1999. It has a weight of 24.6 tons and a track width of 600 mm. The transport dimensions are 9.9 meters in length, 3.29 meters in width, and 3.71 meters in height. The machine features a tear-out force of 120 kN, a dredging depth of 6.5 meters, and a maximum horizontal reach of 10 meters. The bucket capacity is 1.3 cubic meters.

Crawler Excavators Volvo EC230B

Visit Volvo live at

Technical specs - EC230B Volvo

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
24.6 t
Transport length
9.9 m
Transport width
3.29 m
Transport height
3.71 m
Bucket capacity
1.3 m³
Track width
600 mm
Max. Reach horizontal
10 m
Dredging depth
6.5 m
Tear-out force
120 kN
Engine manuf.
Volvo
Engine type
TD 63 KIE
Engine power
127 kW
Displacement
5.48 l
Revolutions at max torque
2100 rpm
No. of cylinders
6
Cylinder bore x stroke
98.43x120 mm

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, boom, bucket width, model series, dimension lxwxh, max. torque, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Volvo EC230B FAQ

When was the Volvo EC230B manufactured?

The Volvo EC230B was manufactured from 1998 to 1999.

How much does the Volvo EC230B weigh?

The Volvo EC230B weighs 24.6 tons.

What are the transport dimensions of the Volvo EC230B crawler excavator?

The Volvo EC230B has a transport length of 9.9 meters, a transport width of 3.29 meters, and a transport height of 3.71 meters.

What is the track width of the Volvo EC230B's undercarriage?

The Volvo EC230B has a track width of 600 mm.

What are the dredging depth and maximum horizontal reach of the Volvo EC230B?

The Volvo EC230B has a dredging depth of 6.5 meters and a maximum horizontal reach of 10 meters.

What is the tear-out force of the Volvo EC230B?

The Volvo EC230B has a tear-out force of 120 kN.

What is the bucket capacity of the Volvo EC230B excavator?

The Volvo EC230B excavator has a bucket capacity of 1.3 cubic meters.

How much is a Volvo EC230B Crawler excavator (1998u20131999) worth?

The residual value of the Volvo EC230B depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
