EC220ENH Volvo excavator specs & Dimensions (2019 - 2026)

Volvo EC220ENH is a crawler excavator manufactured since 2019, with a weight of 23.59 tons. It features a track width of 600 mm, a…

Volvo EC220ENH is a crawler excavator manufactured since 2019, with a weight of 23.59 tons. It features a track width of 600 mm, a transport length of 9.795 meters, a transport width of 2.54 meters, and a transport height of 3.335 meters. The machine has a tear-out force of 125 kN, a dredging depth of 5.76 meters, and a maximum horizontal reach of 9.09 meters. It is equipped with a bucket capacity of 0.92 cubic meters and includes special equipment such as air conditioning and a diesel particulate filter.

Crawler Excavators Volvo EC220ENH
Crawler Excavators Volvo EC220ENH
Crawler Excavators Volvo EC220ENH
Crawler Excavators Volvo EC220ENH
Crawler Excavators Volvo EC220ENH
Crawler Excavators Volvo EC220ENH
Crawler Excavators Volvo EC220ENH
Crawler Excavators Volvo EC220ENH
Crawler Excavators Volvo EC220ENH
Crawler Excavators Volvo EC220ENH
Crawler Excavators Volvo EC220ENH
Crawler Excavators Volvo EC220ENH

Visit Volvo live at

Technical specs - EC220ENH Volvo

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
23.59 t
Transport length
9.795 m
Transport width
2.54 m
Transport height
3.335 m
Bucket capacity
0.92 m³
Track width
600 mm
Boom
MB
Max. Reach horizontal
9.09 m
Dredging depth
5.76 m
Tear-out force
125 kN
Model series
EC
Engine manuf.
Volvo
Engine type
D6J
Engine power
128 kW
Displacement
5.7 l
Revolutions at max torque
1800 rpm
Max. torque
850/1350 Nm
No. of cylinders
6
Cylinder bore x stroke
98x126 mm
Emission level
V

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, bucket width, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Volvo EC220ENH FAQ

When was the Volvo EC220ENH manufactured?

The Volvo EC220ENH was first produced in 2019.

How much does the Volvo EC220ENH weigh?

The Volvo EC220ENH weighs 23.59 tons.

What are the transport dimensions of the Volvo EC220ENH crawler excavator?

The Volvo EC220ENH has a transport length of 9.8 meters, a transport width of 2.54 meters, and a transport height of 3.34 meters.

What is the fuel consumption range of the Volvo EC220ENH crawler excavator?

The Volvo EC220ENH crawler excavator has a fuel consumption range of 10 to 20 liters per hour.

What is the track width of the Volvo EC220ENH's undercarriage?

The Volvo EC220ENH has a track width of 600 mm.

What are the excavation performance specifications of the Volvo EC220ENH?

The Volvo EC220ENH has a dredging depth of 5.76 meters, a maximum horizontal reach of 9.09 meters, and is equipped with a monobloc boom.

What is the tear-out force of the Volvo EC220ENH?

The Volvo EC220ENH has a tear-out force of 125 kN.

What is the bucket capacity of the Volvo EC220ENH excavator?

The bucket capacity of the Volvo EC220ENH excavator is 0.92 cubic meters.

How much is a Volvo EC220ENH Crawler excavator (2019u20132025) worth?

The residual value of the Volvo EC220ENH depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
