EC220EN Volvo excavator specs & Dimensions (2019 - 2026)

Volvo EC220EN is a Crawler Excavator manufactured since 2019, with a weight of 21.28 tons. It features a track width of 600 mm, a …

Volvo EC220EN is a Crawler Excavator manufactured since 2019, with a weight of 21.28 tons. It features a track width of 600 mm, a transport length of 9.795 meters, a transport width of 2.8 meters, and a transport height of 3.27 meters. The machine has a tear-out force of 146 kN, a dredging depth of 5.83 meters, and a maximum horizontal reach of 9.09 meters. The bucket capacity is 0.92 cubic meters. Special equipment includes air conditioning and a diesel particulate filter.

Crawler Excavators Volvo EC220EN
Crawler Excavators Volvo EC220EN
Crawler Excavators Volvo EC220EN
Crawler Excavators Volvo EC220EN
Crawler Excavators Volvo EC220EN
Crawler Excavators Volvo EC220EN
Crawler Excavators Volvo EC220EN
Crawler Excavators Volvo EC220EN
Crawler Excavators Volvo EC220EN
Crawler Excavators Volvo EC220EN
Crawler Excavators Volvo EC220EN
Crawler Excavators Volvo EC220EN

Visit Volvo live at

Technical specs - EC220EN Volvo

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
21.28 t
Transport length
9.795 m
Transport width
2.8 m
Transport height
3.27 m
Bucket capacity
0.92 m³
Track width
600 mm
Boom
MB
Max. Reach horizontal
9.09 m
Dredging depth
5.83 m
Tear-out force
146 kN
Model series
EC
Engine manuf.
Volvo
Engine type
D6J
Engine power
128 kW
Displacement
5.7 l
Revolutions at max torque
1800 rpm
Max. torque
850/1350 Nm
No. of cylinders
6
Cylinder bore x stroke
98x126 mm
Emission level
V

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, bucket width, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Volvo EC220EN FAQ

When was the Volvo EC220EN manufactured?

The Volvo EC220EN was first produced in 2019.

How much does the Volvo EC220EN weigh?

The Volvo EC220EN weighs 21.28 tons.

What are the transport dimensions of the Volvo EC220EN?

The Volvo EC220EN has a transport length of 9.8 meters, a transport width of 2.8 meters, and a transport height of 3.27 meters.

What is the fuel consumption range of the Volvo EC220EN?

The Volvo EC220EN has a fuel consumption range of 10 to 20 liters per hour.

What is the track width of the Volvo EC220EN's undercarriage?

The Volvo EC220EN has a track width of 600 mm.

What are the excavation performance specifications of the Volvo EC220EN?

The Volvo EC220EN has a dredging depth of 5.83 meters, a maximum horizontal reach of 9.09 meters, and is equipped with a Monobloc boom.

What is the tear-out force of the Volvo EC220EN?

The Volvo EC220EN has a tear-out force of 146 kN.

What is the bucket capacity of the Volvo EC220EN?

The Volvo EC220EN has a bucket capacity of 0.92 cubic meters.

How much is a Volvo EC220EN Crawler excavator (2019u20132025) worth?

The residual value of the Volvo EC220EN depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
