Technical specs - EC220ELR Volvo
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 23.69 t
- Transport length
- 12.88 m
- Transport width
- 3.19 m
- Transport height
- 3.27 m
- Bucket capacity
- 0.92 m³
- Bucket capacity min.
- 0.48 m³
- Bucket capacity max.
- 1.44 m³
- Track width
- 800 mm
- Boom
- MB
- Max. Reach horizontal
- 15.8 m
- Dredging depth
- 12.1 m
- Tear-out force
- 68 kN
- Model series
- EC
- Engine manuf.
- Volvo
- Engine type
- D6J
- Engine power
- 128 kW
- Displacement
- 5.7 l
- Revolutions at max torque
- 1800 rpm
- Max. torque
- 850/1350 Nm
- No. of cylinders
- 6
- Cylinder bore x stroke
- 98x126 mm
- Emission level
- V
More technical details, like: undercarriage, bucket width, dimension lxwxh are available in the full technical specs.
Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket
Special equipment
- Diesel particulate filter
-
Yes
- Track adjustment
-
No
- Blade
-
No
- Cabin adjustment
-
No
- Overload alert
-
No
- Material Handling Excavator
-
No
- Aircondition
-
Yes
- Quick hitch hydr.
-
No
- Quick hitch mech.
-
No
Download datasheets (PDF)
Volvo EC220ELR FAQ
How much does the Volvo EC220ELR weigh?
What are the transport dimensions of the Volvo EC220ELR?
What is the fuel consumption range of the Volvo EC220ELR?
What is the track width of the Volvo EC220ELR's undercarriage?
What are the excavation performance specifications of the Volvo EC220ELR?
What are the power ratings of the Volvo EC220ELR?
What is the bucket capacity of the Volvo EC220ELR crawler excavator?
