EC210B Volvo excavator specs & Dimensions (2016 - 2018)

Volvo EC210B is a Crawler Excavator manufactured from 2016 to 2018. It has a weight of 20.84 tons and a track width of 600 mm. The…

Volvo EC210B is a Crawler Excavator manufactured from 2016 to 2018. It has a weight of 20.84 tons and a track width of 600 mm. The transport dimensions are 9.75 meters in length, 2.99 meters in width, and 2.93 meters in height. The machine features a tear-out force of 122.6 kN, a dredging depth of 6.33 meters, and a maximum horizontal reach of 9.54 meters. The bucket width is 1.125 meters with a capacity of 0.92 cubic meters.

Crawler Excavators Volvo EC210B
Crawler Excavators Volvo EC210B
Crawler Excavators Volvo EC210B
Crawler Excavators Volvo EC210B
Crawler Excavators Volvo EC210B
Crawler Excavators Volvo EC210B

Visit Volvo live at

Technical specs - EC210B Volvo

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
20.84 t
Transport length
9.75 m
Transport width
2.99 m
Transport height
2.93 m
Bucket capacity
0.92 m³
Track width
600 mm
Boom
MB
Max. Reach horizontal
9.54 m
Dredging depth
6.33 m
Tear-out force
122.6 kN
Bucket width
1.125 m
Model series
EC
Engine manuf.
Volvo
Engine type
D 6 D-EAE 2
Engine power
107 kW
Displacement
5.7 l
Revolutions at max torque
1900 rpm

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Volvo EC210B FAQ

When was the Volvo EC210B manufactured?

The Volvo EC210B was manufactured from 2016 to 2018.

How much does the Volvo EC210B weigh?

The Volvo EC210B weighs 20.84 tons.

What are the transport dimensions of the Volvo EC210B crawler excavator?

The Volvo EC210B has a transport length of 9.75 meters, a transport width of 2.99 meters, and a transport height of 2.93 meters.

What is the track width of the Volvo EC210B's undercarriage?

The Volvo EC210B has a track width of 600 mm.

What are the excavation performance specifications of the Volvo EC210B?

The Volvo EC210B has a dredging depth of 6.33 meters, a maximum horizontal reach of 9.54 meters, and is equipped with a monobloc boom.

What are the power ratings of the Volvo EC210B?

The source data does not provide power rating information for the Volvo EC210B.

What are the specifications of the primary work tool on the Volvo EC210B?

The primary work tool of the Volvo EC210B has a bucket capacity of 0.92 cubic meters and a bucket width of 1.125 meters.

How much is a Volvo EC210B Crawler excavator (2016u20132018) worth?

The residual value of the Volvo EC210B depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
